Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 860 × 780 × 800 mm | |
|---|---|---|
| Seat height | 470 mm | |
| Seat width | 680 mm | |
| Seat depth | 580 mm | |
| Backrest height | 420 mm | |
| Armrest height above seat | 180 mm | |
| Under-seat clearance | 150 mm | |
| Leg diameter | 18 mm | |
| Included throw pillow dimensions | 400 x 400 mm | |
| Required entry clearance | 1090 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended static load capacity | 150 kg | |
|---|---|---|
| Net weight | 18 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Back foam density | 30 kg/m³ | |
| Martindale abrasion resistance | 50000 cycles | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery surface | 1.0mm thick caramel faux leather (PU) with scratch-resistant, wipe-clean finish | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam wrapped with soft polyester fibre layer | |
| Backrest core | Medium-density polyurethane foam with vertical channel tufting detailing | |
| Internal support frame | 1.2mm thick powder-coated steel tube frame | |
| Support legs | Splayed 18mm diameter matte black powder-coated iron legs | |
| Included throw pillow | Woven polyester fabric with dark vertical stripes, filled with hollow polyester fibre | |
| Leg foot pads | Non-slip PE plastic floor protection pads fitted to each leg base | |
| Seat edge finishing | Tight tailored upholstery with rounded stitched perimeter | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Base structure | Fixed stationary non-swivel, non-reclining, non-rocking four-leg base | |
|---|---|---|
| Back support | Integrated wrap-around barrel back enclosing seated user for lateral support | |
| Arm support | Continuous sloped integrated armrests connected directly to backrest frame | |
| Floor protection | Non-marking foot pads prevent scuffing to hard floor surfaces under load | |
| Accessory inclusion | One matching striped accent throw pillow included for lumbar support | |
| Assembly requirement | Partial knock-down assembly requiring leg attachment to seat frame | |
| Cleaning function | Faux leather surface supports wipe-clean maintenance with damp cloth | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Living room accent seating | Placed beside sofas or coffee tables for supplementary guest seating | |
|---|---|---|
| Bedroom reading corner | Positioned near windows or bookshelves for relaxed single-person seating | |
| Office reception area | Used in lobby or waiting zones for visitor seating | |
| Studio apartment compact seating | Suitable for small space layouts due to rounded space-efficient silhouette | |
| Commercial lounge space | Deployed in cafe, co-working or hotel lounge break-out areas | |
| Vanity seating application | Paired with dressing tables for upright comfortable seating | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Strength, durability and safety requirements for domestic seating furniture | |
|---|---|---|
| EN 1021-1:2014 | Ignition resistance standard for upholstered furniture (cigarette test) |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable for wooden and metal household furniture | |
|---|---|---|
| GB 28007-2011 | Formaldehyde emission limits applicable for upholstered furniture components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable for wooden and metal household furniture; 2. GB 28007-2011: Formaldehyde emission limits applicable for upholstered furniture components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
