Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 840 × 870 × 830 mm | |
|---|---|---|
| Chair seat height | 470 mm | |
| Chair seat width | 635 mm | |
| Chair seat depth | 546 mm | |
| Chair arm height from floor | 600 mm | |
| Chair back height from seat | 360 mm | |
| Side table marble top thickness | 20 mm | |
| Side table pedestal base footprint | 400 x 400 mm | |
| Set circular arrangement footprint | 2600 x 2600 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-chair static weight capacity | 200 kg | |
|---|---|---|
| Per-chair net weight | 26.5 kg | |
| Side table top static load capacity | 77 kg | |
| Seat foam density | 40 kg/m³ | |
| Seat foam thickness | 80 mm | |
| Velvet upholstery abrasion resistance | 50000 double rubs | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Chair upholstery | Terracotta matte velvet fabric, 0.8mm face thickness | |
|---|---|---|
| Chair internal frame | Solid pine + engineered hardwood frame, 25mm structural thickness | |
| Chair seat support | Pocketed spring core wrapped in high-density polyurethane foam | |
| Chair back and arm fill | 35kg/m³ soft polyurethane foam wrapped in Dacron batting | |
| Chair swivel base | Gold powder-coated carbon steel circular ring, 2mm wall thickness | |
| Swivel mechanism | Steel ball-bearing 360° rotation plate, 3mm plate thickness | |
| Side table top | White natural marble with gray veining, polished sealed finish | |
| Side table edge trim | Polished stainless steel metal trim, 1.5mm thickness | |
| Side table pedestal base | Brushed silver stainless steel tapered trapezoidal column, 1.2mm wall thickness | |
| Seam construction | 8 stitches per inch invisible seam stitching | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Chair rotation | 360° friction-free swivel on ball-bearing base, no recline function | |
|---|---|---|
| Seating comfort | Enveloping curved arm/back design with 100° relaxed back angle | |
| Table function | Central flat top for drink, decor and small item placement, no lower shelf | |
| Table stability | Tapered flared pedestal base distributes weight evenly across floor contact | |
| Floor protection | Felt glides integrated under swivel ring and table base to prevent scratches | |
| Cleaning requirement | Spot-clean only for velvet upholstery, wipe marble with non-abrasive cleaner | |
| Assembly requirement | Minimal assembly required for table, chairs ship fully assembled | |
| Swivel base ring diameter per chair | 700 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total carton count | 5 | |
|---|---|---|
| Chair carton dimensions per unit | 880 x 910 x 870 mm | |
| Table carton dimensions | 650 x 650 x 600 mm | |
| Total shipment gross weight | 158 kg | |
| Total shipment volume | 3.08 CBM | |
| Assembly time for full set | 30 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception areas | Suitable for guest waiting zones with soft, inviting low-profile seating | |
|---|---|---|
| Residential living rooms | Fits open-plan living spaces as a dedicated conversation nook | |
| Lounge and break areas | Appropriate for employee relaxation zones in modern workplaces | |
| Hotel lobbies and guest suites | Matches upscale contemporary hospitality interior design schemes | |
| High-end retail waiting areas | Suitable for boutique store customer waiting spaces | |
| Co-working common areas | Supports casual small group discussion in flexible workspaces | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applies to strength, durability and safety for domestic seating | |
|---|---|---|
| EN 13722:2004 | Applies to strength and stability for domestic tables | |
| EN 1022:2018 | Applies to stability requirements for seating furniture |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Applies to performance requirements for lounge seating | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Applies to performance requirements for occasional tables |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to general technical requirements for wooden furniture (chair frames) | |
|---|---|---|
| GB/T 19001-2016 | Applies to quality management system for furniture manufacturing | |
| GB 20400-2006 | Applies to leather/fabric upholstery harmful substance limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to general technical requirements for wooden furniture (chair frames); 2. GB/T 19001-2016: Applies to quality management system for furniture manufacturing; 3. GB 20400-2006: Applies to leather/fabric upholstery harmful substance limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
