Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 770 x 740 x 780 mm | |
|---|---|---|
| Seat height (floor to seat top) | 490 mm | |
| Seat width (between integrated armrests) | 560 mm | |
| Seat depth (front edge to back shell) | 540 mm | |
| Backrest height (seat top to shell peak) | 360 mm | |
| Armrest height (floor to arm top) | 640 mm | |
| Metal leg tube diameter | 16 mm | |
| Frame cross-brace height above floor | 180 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load capacity | 136 kg | |
|---|---|---|
| Net product weight | 18 kg | |
| Seat foam density | 40 kg/m³ | |
| Seat foam thickness | 120 mm | |
| Back foam thickness | 60 mm | |
| Foam rebound rate | 45% | |
| Recommended warranty period (commercial use) | 1 year | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery surface | 1.0 mm thick light beige PU/faux leather | |
|---|---|---|
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat cushion core | High-density polyurethane foam | |
| Back/arm shell core | Plywood inner shell with steel reinforcement, foam-wrapped | |
| Structural frame | Matte black powder-coated carbon steel tube | |
| Floor contact glides | Non-marking injection-molded polypropylene glides | |
| Stitching detail | Matching light beige polyester thread, 8 mm seam pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel | |
| Five-star Base Material Thickness | Metal base wall 3.5 mm; diameter 700 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating posture | Fixed relaxed 105° reclined seat-back angle | |
|---|---|---|
| Base stability | Four-point curved sled frame with central cross-brace | |
| Floor protection | Integrated plastic glides eliminate metal-to-floor contact | |
| Cleaning performance | Smooth non-porous faux leather surface allows wipe-clean maintenance | |
| Arm support | Continuous integrated armrests form part of the wrap shell for full side support | |
| Assembly requirement | Knock-down assembly with provided hardware, no specialized tools needed | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office reception and waiting areas | Compact footprint and durable upholstery suit high-traffic guest seating | |
|---|---|---|
| Residential living room accent seating | Minimalist modern design complements contemporary living room layouts | |
| Bedroom casual reading nooks | Relaxed seat posture provides comfortable casual seating for bedroom spaces | |
| Hotel lobby and guest lounge areas | Neutral beige finish and commercial-grade construction fit hospitality settings | |
| Co-working breakout zones | Lightweight sled base allows easy reconfiguration for flexible workspaces | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Seating stability recommendation | EN 1022:2018 | |
|---|---|---|
| Upholstered seating strength recommendation | EN 16139:2013 |
US and Canada office-furniture standards
| Lounge seating durability recommendation | ANSI/BIFMA X2020 |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 28007 | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18584 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 28007; 2. Formaldehyde emission recommendation: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
