Automatic mm / inch conversion · Core engineering specifications
| Overall single chair dimensions | 750 x 730 x 900 mm | |
|---|---|---|
| Single chair seat height | 480 mm | |
| Single chair seat width | 500 mm | |
| Single chair seat depth | 600 mm | |
| Single chair back height (seat to top) | 420 mm | |
| Chair leg height | 180 mm | |
| Side table overall dimensions | 450 x 450 x 550 mm | |
| Side table tabletop diameter | 450 mm | |
| Side table base bottom diameter | 300 mm | |
| Throw pillow dimensions per chair | 450 x 450 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Single chair net weight | 20.5 kg | |
|---|---|---|
| Single chair static weight capacity | 150 kg | |
| Side table top static load capacity | 30 kg | |
| Set total seating capacity | 2 persons | |
| Cushion foam density | 38 kg/m³ | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Recommended warranty period for commercial use | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Chair outer shell upholstery | Terracotta red matte performance fabric | |
|---|---|---|
| Chair seat and inner back upholstery | Cream off-white matte performance fabric | |
| Chair seat fill | High-density polyurethane foam with top fiber wrap | |
| Chair internal frame | 25mm thick solid kiln-dried hardwood frame | |
| Chair seat support | Elastic webbing suspension | |
| Chair legs | 18mm diameter tapered black powder-coated steel with polished gold foot caps | |
| Side table tabletop | 8mm thick clear tempered glass | |
| Side table pedestal base | 1.2mm thick cold-rolled steel, terracotta red powder coat finish | |
| Side table foot ring | Polished gold-finish stainless steel trim ring at floor contact | |
| Seam stitching | Polyester thread with 8mm stitch pitch | |
| Included throw pillows | Matching cream fabric covers with polyester fiber fill | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating posture support | Enveloping curved barrel back provides 180-degree upper body lateral support for relaxed lounge seating | |
|---|---|---|
| Leg stability | Four outward-angled tapered legs prevent tipping during normal ingress/egress | |
| Floor protection | Gold foot caps include hidden felt glides to prevent hard floor scratching | |
| Side table surface function | Smooth non-porous glass top supports drinkware, reading materials and small decorative items | |
| Assembly requirement | Chair legs attach to pre-installed frame mounting plates with included hardware | |
| Cleaning compatibility | Stain-resistant performance fabric supports spot cleaning with mild soap and water | |
| Layout flexibility | Lightweight chair construction allows repositioning for casual conversation groupings | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office reception lobbies | Arranged beside windows or entryways to provide comfortable waiting seating for 2 visitors | |
|---|---|---|
| Residential living room accent areas | Positioned as a secondary conversation nook beside seating groups for casual relaxation | |
| Hotel lounge and waiting zones | Used in pairs along circulation paths for short-stay guest seating with adjacent drink surface | |
| Sales center display areas | Arranged near model displays to provide rest seating for touring clients as shown in product context | |
| Balcony and sunroom casual seating | Placed near glazing to support light reading and refreshment breaks with elevated view access | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Strength, durability and safety for residential seating, applicable to chair load testing | |
|---|---|---|
| EN 15372:2016 | Durability requirements for contract non-domestic seating, applicable for commercial reception use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Safety and performance standard for lounge and public seating, applicable for commercial installation |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to hardwood frame strength verification | |
|---|---|---|
| GB 20210-2006 | Safety requirements for upholstered furniture, applicable to fire retardant and structural safety testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to hardwood frame strength verification; 2. GB 20210-2006: Safety requirements for upholstered furniture, applicable to fire retardant and structural safety testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
