Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall unit dimensions | 813 x 495 x 1803 mm | |
|---|---|---|
| Lower cabinet exterior dimensions | 775 x 483 x 373 mm | |
| Lower cabinet internal dimensions | 742 x 445 x 343 mm | |
| Top open shelf dimensions | 775 x 229 mm | |
| Middle upper open shelf dimensions | 775 x 292 mm | |
| Lower open shelf (above cabinet) dimensions | 775 x 356 mm | |
| Shelf thickness | 15 mm | |
| Open shelf vertical clearance between tiers | 376 mm | |
| Cabinet door panel dimensions | 380 x 340 mm each | |
| Leveling foot adjustable height range | 15 mm | |
| Integrated top handle height above top shelf | 102 mm | |
| Back panel height (behind lower open shelf) | 376 mm | |
| Internal cabinet shelf thickness | 15 mm | |
| Steel side frame tube thickness | 1.2 mm | |
| Edge banding thickness | 1 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per open shelf static load capacity | 20 kg | |
|---|---|---|
| Unit net weight | 25 kg | |
| Anti-tip kit wall anchor pull-out resistance | 50 kg | |
| Door hinge open/close cycle rating | 50000 cycles | |
| Leveling foot maximum load per foot | 20 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Side frame and leg structure | Powder-coated matte dark carbon steel, 1.2mm wall thickness | |
|---|---|---|
| Open shelves and cabinet top surface | Walnut wood grain laminated MDF, 15mm thick, 1mm PVC edge band | |
| Lower cabinet doors | Matte taupe gray laminated MDF, 15mm thick, handleless push-to-open design | |
| Back panel (lower open shelf section) | Matte gray MDF panel, 3mm thick, attached to frame | |
| Adjustable leveling feet | Reinforced nylon base with steel threaded stem, 15mm adjustment travel | |
| Integrated top handles | Bent powder-coated steel tube matching frame finish, curved top profile |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage layout | Three tiered tapered open display shelves above two-door enclosed cabinet with one fixed interior shelf | |
|---|---|---|
| Leveling adjustment | Four threaded adjustable feet compensate for uneven floor surfaces up to 15mm height difference | |
| Cabinet door operation | Handleless push-to-open mechanism allows door access without protruding hardware | |
| Anti-tip security | Included wall anchor hardware secures unit to wall to prevent forward tipping |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room use | Displays decor, books and small items while concealing clutter in lower cabinet | |
|---|---|---|
| Home office storage use | Holds reference books, office supplies and document storage adjacent to work desks |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops, safety and structural performance requirements | |
|---|---|---|
| EN 12521:2015 | Furniture for domestic use, strength, durability and safety requirements for shelving units | |
| EN 717-1:2004 | Formaldehyde emission determination for wood-based panels, recommended material acceptance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance test standard, suitable for commercial/office use acceptance |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood cabinet and shelf components | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable to structural engineered wood shelf and cabinet panels | |
| GB 28007-2011 | Formaldehyde emission limits for children's and residential furniture, recommended acceptance criteria |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood cabinet and shelf components; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable to structural engineered wood shelf and cabinet panels; 3. GB 28007-2011: Formaldehyde emission limits for children's and residential furniture, recommended acceptance criteria; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
