Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 1630 x 350 x 2010 mm | |
|---|---|---|
| Open shelf depth | 300 mm | |
| Open shelf vertical clearance | 330 mm | |
| Lower cabinet height | 450 mm | |
| Lower cabinet internal shelf height | 380 mm | |
| Perforated divider panel dimensions | 700 x 20 x 1850 mm | |
| Adjustable foot height adjustment range | 20 mm | |
| Perforated panel hole diameter | 8 mm | |
| Perforated panel hole center spacing | 25 mm | |
| Cabinet door thickness | 18 mm | |
| Open shelf panel thickness | 25 mm | |
| Steel frame tube wall thickness | 1.2 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per open shelf static load capacity | 20 kg | |
|---|---|---|
| Perforated panel hanging point load | 5 kg | |
| Unit net weight | 61 kg | |
| Hinge open/close cycle rating | 50000 cycles | |
| Cabinet door opening angle | 110 degrees | |
| Anti-tip restraint load rating | 50 kg | |
| Surface abrasion resistance (laminate shelves) | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Support frame | White powder-coated 25x25mm square steel tubing | |
|---|---|---|
| Open shelf surfaces | Light oak effect melamine laminated particleboard | |
| Lower cabinet doors | Muted grey-blue matte paint finished MDF panels | |
| Privacy divider panel | White powder-coated perforated cold-rolled steel sheet | |
| Hardware components | Zinc-plated steel adjustable leveling feet, concealed hinges | |
| Edge banding | 1mm thick PVC edge trim on all wood panels |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Freestanding room division | Dual-sided open storage separates open-plan office zones | |
|---|---|---|
| Adjustable floor leveling | Rotating feet compensate for uneven carpet or hard flooring | |
| Closed base storage | Two separate 2-door cabinets conceal office supplies and personal items | |
| Perforated accessory hanging | Grid of drilled holes supports hooks, bins and display accessories |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office space division | Separates individual work zones while maintaining visibility and accessible storage | |
|---|---|---|
| Home office display and storage | Stores books, decor and office supplies for residential workspaces |
EU Market Access Requirements* EN Standards
| EN 16122:2012 | Domestic and office storage furniture - Strength and durability requirements, applicable for load testing | |
|---|---|---|
| EN 1022:2018 | Domestic furniture - Seating stability; applies to anti-tip stability verification for freestanding units | |
| EN 14749:2016 | Domestic and kitchen storage units and worktops - Safety requirements for glass and surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture standard for office use, applicable for shelf load and durability testing | |
|---|---|---|
| ANSI/BIFMA X7.1-2021 | Standard for formaldehyde and TVOC emissions from office furniture panels | |
| ANSI/BIFMA e3-2020 | Furniture sustainability standard for material and emissions verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet/shelf wood components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frame and perforated panel |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet/shelf wood components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and perforated panel; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
