Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1397 x 368 x 1829 mm | |
|---|---|---|
| Open shelf count | 4 tiered upper shelves per connected bay | |
| Lower cabinet door count | 4 flat-panel doors (2 per separate cabinet) | |
| Vertical shelf spacing | 325 mm between open shelf tiers | |
| Lower cabinet height | 470 mm | |
| Lower cabinet internal depth | 305 mm | |
| Individual open shelf width | 686 mm per bay | |
| Leveling foot adjustment height | 15 mm | |
| Top carry handle height above top shelf | 100 mm | |
| Frame tube cross-section | 25 x 25 mm square | |
| Top surface overhang past frame | 20 mm front and rear | |
| Cabinet door thickness | 18 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per open shelf static load capacity | 20 kg | |
|---|---|---|
| Net product weight | 59 kg | |
| Anti-tip kit load rating | 50 kg pull resistance | |
| Hinge open/close cycle rating | 20000 cycles | |
| Surface scratch resistance | 1000 abrasion cycles | |
| Anti-tip kit pull resistance | 50 kg | |
| Drawer slide load rating (if applicable) | 15 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Support frame | 0.7mm thick powder-coated black square steel tubing | |
|---|---|---|
| Open shelf surfaces | 15mm thick E1 grade engineered wood with walnut grain laminate | |
| Cabinet doors | 18mm thick matte dark grey laminated engineered wood panels | |
| Leveling feet | Reinforced nylon with non-slip rubber base pads | |
| Back panels behind open shelves | 3mm thick dark grey hardboard backing | |
| Cabinet hardware | Steel concealed hinges with matte black finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Leveling adjustment | Threaded foot pads adjust to compensate for uneven floor surfaces | |
|---|---|---|
| Storage configuration | Combines open display shelving above with concealed cabinet storage below | |
| Anti-tip protection | Wall anchor strap included to secure unit to wall and prevent tipping | |
| Assembly design | Flat-pack knock-down construction with cam-lock fasteners for home assembly |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office study space | Placed against a wall to store reference books, office supplies and decor while hiding clutter in lower cabinets | |
|---|---|---|
| Open-plan living room display | Used to showcase decorative items, media accessories and reading materials with concealed storage for loose items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage furniture | |
|---|---|---|
| EN 12521:2015 | Furniture for domestic use – strength, durability and safety requirements for tables and storage units |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for cabinet/shelf structural integrity | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard specification for furniture-grade panel use in shelves and cabinets | |
| GB/T 17657-2013 | Test methods for surface properties of wood-based panels, applicable for finish durability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for cabinet/shelf structural integrity; 2. GB/T 4897.3-2003: Particleboard specification for furniture-grade panel use in shelves and cabinets; 3. GB/T 17657-2013: Test methods for surface properties of wood-based panels, applicable for finish durability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
