Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2000 x 400 x 1970 mm | |
|---|---|---|
| Pegboard panel dimensions | 450 x 35 x 1800 mm | |
| Shelf depth | 300 mm | |
| Pegboard hole diameter | 8 mm | |
| Pegboard hole center spacing | 25 mm | |
| Lower cabinet internal height | 350 mm | |
| Hanging rail clearance height | 1100 mm | |
| Adjustable foot height range | 15 mm | |
| Lower cabinet door panel thickness | 18 mm | |
| Steel frame tube thickness | 1.2 mm | |
| Open shelf vertical clearance (upper tiers) | 350 mm | |
| Lower open display shelf vertical clearance | 250 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static load per open shelf | 15 kg | |
|---|---|---|
| Static load per cabinet shelf | 20 kg | |
| Hanging rail static load | 25 kg | |
| Pegboard per-hook load | 3 kg | |
| Unit total static load | 180 kg | |
| Product net weight | 60 kg | |
| Anti-tip wall attachment load rating | 50 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Support frame | White powder-coated square steel tube, 1.2mm wall thickness, corrosion-resistant finish | |
|---|---|---|
| Open shelf panels | Light oak melamine-faced engineered wood, 18mm thickness, scratch-resistant wipe-clean surface | |
| Closed cabinet doors | Brown matte melamine-faced engineered wood, 18mm thickness, soft-touch finish | |
| Pegboard divider | Perforated white powder-coated steel panel, 1.0mm thickness, uniform hole pattern | |
| Hanging rail | White powder-coated round steel tube, 25mm diameter, fixed to right-side frame | |
| Leveling feet | Reinforced nylon base with steel threaded stem, adjustable for uneven floors |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Floor leveling | Threaded adjustable feet on each vertical leg, 15mm adjustment range to stabilize on uneven floors | |
|---|---|---|
| Pegboard accessory compatibility | Perforated panel accepts standard 25mm-spaced peg hooks for hanging office supplies, tools or decor | |
| Dual storage configuration | Mixed open display shelves for books/decor and closed lower cabinets for concealed storage of unsightly items | |
| Integrated garment hanging | Fixed horizontal upper rail on right section for hanging outerwear, bags or garment accessories |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open office zoning | Suitable for dividing open-plan work zones while providing accessible storage for office supplies and decor | |
|---|---|---|
| Home office or studio | Ideal for home workspaces combining book storage, accessory hanging and light garment storage |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units, safety and performance requirements for freestanding shelving | |
|---|---|---|
| EN 1022:2018 | Furniture seating and storage stability test method, applicable for anti-tip performance verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard, applicable for commercial office use load requirements |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for wood panel dimensional and finish quality | |
|---|---|---|
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables and storage units, applicable for shelf load validation | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for wood panel dimensional and finish quality; 2. GB/T 10357.1-2013: Furniture mechanical performance test for tables and storage units, applicable for shelf load validation; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
