| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1800 x 330 x 1800 mm | |
|---|---|---|
| Single bay width | 900 mm | |
| Top open shelf depth | 200 mm | |
| Bottom open shelf depth | 300 mm | |
| Vertical clearance between open shelves | 330 mm | |
| Lower cabinet height | 600 mm | |
| Lower cabinet internal depth | 280 mm | |
| Individual cabinet door dimensions | 450 x 580 mm | |
| Leveling foot adjustment height | 15 mm | |
| Floor clearance under cabinet base | 20 mm | |
| Metal frame tube profile | 25 x 25 mm | |
| Shelf panel thickness | 18 mm | |
| Cabinet door panel thickness | 16 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static load capacity | 330 kg | |
|---|---|---|
| Net product weight | 55 kg | |
| Hinge open/close cycle rating | 50000 cycles | |
| Wall anti-tip connection load rating | 50 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upright frame | Powder-coated matte black steel square tube | |
|---|---|---|
| Open shelf panels | Dark walnut-look engineered wood with melamine laminate | |
| Cabinet door panels | Medium density fiberboard with matte grey laminate | |
| Cabinet carcass | Particleboard core with matching dark laminate | |
| Hardware | Zinc-plated steel hinges, screws, and wall anchors | |
| Leveling feet | Reinforced nylon with threaded steel insert |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Leveling adjustment | Threaded feet rotate to adjust height 15mm for uneven floors | |
|---|---|---|
| Enclosed storage | Four flat-panel doors conceal lower cabinet storage for clutter control | |
| Anti-tip safety | Wall anchor straps secure top of frame to wall to prevent tipping | |
| Leaning installation | Freestanding unit rests against wall with frame angled slightly backward |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office book storage | Holds books, files, and office supplies with concealed clutter storage below | |
|---|---|---|
| Living room display storage | Displays decor and collectibles on open shelves with hidden media storage |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage furniture safety requirements, applicable to cabinet units | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating/storage stability test methods |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood cabinet components | |
|---|---|---|
| GB/T 17657-2013 | Test methods for surface properties of wood-based furniture panels | |
| GB 28007-2011 | Furniture safety general requirements, applicable to anti-tip performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood cabinet components; 2. GB/T 17657-2013: Test methods for surface properties of wood-based furniture panels; 3. GB 28007-2011: Furniture safety general requirements, applicable to anti-tip performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
