Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1800 x 350 x 1800 mm | |
|---|---|---|
| Left double-door cabinet dimensions | 600 x 350 x 400 mm | |
| Middle double-door cabinet dimensions | 600 x 350 x 400 mm | |
| Right open lower shelf dimensions | 600 x 350 x 350 mm | |
| Open shelf clearance height | 350 mm | |
| Hanging rod clearance below top shelf | 1050 mm | |
| Shelf board thickness | 15 mm | |
| Metal frame tubing diameter | 25 mm | |
| Cabinet door thickness | 15 mm | |
| Leveling foot adjustment range | 15 mm | |
| Top shelf width per segment | 600 mm | |
| Hanging rod diameter | 25 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Individual open shelf static load capacity | 10 kg | |
|---|---|---|
| Unit net weight | 55 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Vertical support frame | White powder-coated 25mm steel tubing | |
|---|---|---|
| Open shelf surfaces | 15mm light wood-grain melamine-faced particleboard | |
| Cabinet doors and back panels | 15mm sage grey matte MDF panels | |
| Integrated hanging rod | White epoxy-coated steel tubing | |
| Leveling feet | Polymer base with steel threaded stem | |
| Door hardware | Pressed steel concealed hinges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Leveling foot adjustment | Threaded feet adjust to compensate for uneven floor surfaces | |
|---|---|---|
| Closed cabinet storage | Two sets of double-door cabinets provide concealed lower storage | |
| Clothing hanging function | Frame-mounted steel rod supports hanging garments in the right segment | |
| Anti-tip anchoring compatibility | Frame designed for wall anchor installation to prevent tipping |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Entryway combined storage | Hangs outerwear and stores entry essentials in lower closed cabinets | |
|---|---|---|
| Living room display storage | Showcases decor items, media and hides clutter in closed cabinets |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 Office storage furniture - Safety requirements | Applicable for structural stability and anti-tip performance verification | |
|---|---|---|
| EN 12221-1:2005 Domestic storage units - Safety requirements | Applicable for load capacity and sharp edge safety verification |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for dimensional tolerance, finish quality and structural stability verification | |
|---|---|---|
| GB/T 24821-2009 General technical requirements for metal furniture | Applicable for powder-coated metal frame strength and finish durability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for dimensional tolerance, finish quality and structural stability verification; 2. GB/T 24821-2009 General technical requirements for metal furniture: Applicable for powder-coated metal frame strength and finish durability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
