| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 775 x 381 x 1800 mm | |
|---|---|---|
| Open shelf count | 3 tiers | |
| Lower cabinet door count | 2 units | |
| Top open shelf depth | 220 mm | |
| Middle open shelf depth | 280 mm | |
| Third open shelf (cabinet top) depth | 381 mm | |
| Open shelf clearance between tiers | 315 mm | |
| Lower cabinet internal height | 600 mm | |
| Lower cabinet internal width per compartment | 360 mm | |
| Adjustable leveler foot height adjustment range | 25 mm | |
| Top integrated carry handle height above top shelf | 100 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per open shelf static load capacity | 18 kg | |
|---|---|---|
| Unit net weight reference | 25 kg | |
| Anti-tip wall restraint load rating | 50 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Frame construction | 25mm diameter powder-coated dark steel tube | |
|---|---|---|
| Open shelf panels | 15mm thick engineered wood with dark brown melamine finish | |
| Lower cabinet door panels | 15mm thick engineered wood with matte grey melamine finish | |
| Leveler feet | Injection-molded polypropylene base with steel threaded stud | |
| Cabinet internal shelf | 15mm thick engineered wood matching cabinet body finish | |
| Edge banding | 0.8mm thick PVC edge trim on all engineered wood panels |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Floor leveling adjustment | Screw-in adjustable feet at 4 legs, 25mm total travel | |
|---|---|---|
| Top carry handles | Integrated U-shaped steel handles at upper frame posts | |
| Concealed storage | Dual-door lower cabinet with fixed internal shelf | |
| Anti-tip safety | Wall anchor bracket for rear frame attachment |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office storage | Suitable for book and office supply storage alongside desks | |
|---|---|---|
| Living room display | Ideal for decor, books, and small item display in living spaces |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage furniture | |
|---|---|---|
| EN 1022:2018 | Stability testing requirements for freestanding storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet and shelf components | |
|---|---|---|
| GB/T 24821-2009 | Safety requirements for furniture storage units, applicable to anti-tip performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet and shelf components; 2. GB/T 24821-2009: Safety requirements for furniture storage units, applicable to anti-tip performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
