Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 1880 x 380 x 2030 mm | |
|---|---|---|
| Pegboard divider panel dimensions | 600 x 20 x 1830 mm | |
| Adjustable leveler foot height adjustment | 15 mm | |
| Lower closed cabinet compartment height | 450 mm | |
| Open shelf vertical clearance (upper tiers) | 320 mm | |
| Clothes hanging rod clearance below top shelf | 900 mm | |
| Individual cabinet door dimensions | 320 x 440 mm | |
| Shelf thickness (wood laminate) | 18 mm | |
| Metal frame tubing wall thickness | 1.2 mm | |
| Pegboard hole diameter | 6 mm | |
| Right end open shelf depth | 300 mm | |
| Top shelf depth | 280 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Individual open shelf static load capacity | 15 kg | |
|---|---|---|
| Product net weight | 87 kg | |
| Recommended wall anchor tensile load | 50 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Support frame | White powder-coated 25mm square tubular steel | |
|---|---|---|
| Shelves and cabinet carcass | E1 grade engineered wood with light oak laminate finish | |
| Cabinet doors and accent back panels | 18mm thick MDF with matte sage green paint finish | |
| Left divider panel | White perforated powder-coated steel pegboard | |
| Clothes hanging rod | 19mm diameter white powder-coated steel tube | |
| Hardware and feet | Zinc-plated steel hardware with nylon-tipped adjustable levelers |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Pegboard accessory mounting | Compatible with standard 6mm pegboard hooks and organizers | |
|---|---|---|
| Shelf height adjustability | 50mm incremental shelf height adjustment along frame uprights | |
| Cabinet door operation | Handleless hinged doors for concealed lower storage | |
| Open-back dual-side access | Double-sided accessible shelves for room divider placement |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office space division | Separates work zones while providing book, decor and accessory storage | |
|---|---|---|
| Residential entryway organization | Combines hanging storage, closed shoe storage and display for entry use |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units safety requirements, applicable to storage performance | |
|---|---|---|
| EN 1022:2018 | Furniture seating and storage stability testing, applicable to freestanding stability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable for office and contract use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frame and pegboard |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and pegboard; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
