Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W×D×H) | 630 × 650 × 1120 mm | |
|---|---|---|
| Seat width | 520 mm | |
| Seat depth | 500 mm | |
| Adjustable seat height (floor to seat top) | 540 mm | |
| Backrest height (seat top to back top) | 580 mm | |
| Four-star base cross diameter | 650 mm | |
| Gas lift cylinder diameter | 50 mm | |
| Armrest height (seat top to arm top) | 200 mm | |
| Backrest width at widest point | 520 mm | |
| Floor glide pad dimensions | 30 × 30 mm | |
| Seat foam thickness | 80 mm | |
| Backrest foam thickness | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended maximum static user load | 150 kg | |
|---|---|---|
| Net weight reference | 25 kg | |
| Seat swivel range | 360 degrees | |
| Gas lift height adjustment stroke | 140 mm | |
| Recommended daily usage duration | 8 hours | |
| Upholstery surface cleanability | Wipe-clean with mild detergent | |
| Base static load rating | 500 kg | |
| Standard warranty period | 5 years | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back outer upholstery | 1.0mm thick light blue PU/faux leather with contrast edge stitching | |
|---|---|---|
| Seat core padding | 80mm thick 45kg/m³ density high-resilience molded polyurethane foam | |
| Backrest core padding | 50mm thick 40kg/m³ density molded polyurethane foam | |
| Four-prong base construction | Polished chrome-plated die-cast aluminum, 8mm wall thickness at leg joints | |
| Height adjustment mechanism | Class 3 carbon steel gas lift with 50mm outer diameter, black plastic height adjustment lever | |
| Seat support mounting plate | 3mm thick stamped steel plate connecting seat frame to gas lift | |
| Armrest structure | Integrated upholstered armrests with 2mm thick internal steel support frame, continuous wrap-around design matching seat and back | |
| Floor contact components | 30mm square non-marking black nylon glides fitted to each base leg end | |
| Internal seat/back frame | 12mm thick multi-layer plywood structural panel under foam padding | |
| Stitching specification | 8 stitches per 30mm seam pitch, matching light blue thread with defined edge piping | |
| Gas lift cover | Brushed chrome-plated steel telescopic outer cover surrounding the gas lift cylinder | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Height adjustment operation | Pneumatic gas lift adjusted via side-mounted lever under seat, allowing 140mm total vertical seat height travel to accommodate different user heights | |
|---|---|---|
| Swivel function | Full 360-degree horizontal rotation around central gas lift axis, with no rotation lock to enable easy user positioning in meeting spaces | |
| Base mobility | Stationary fixed position with non-marking nylon glides, no rolling casters designed for low-movement conference and visitor areas | |
| Integrated arm support | Fixed wrap-around armrests at 200mm height above seat, providing continuous forearm support during seated meetings with no height or width adjustment | |
| Upright seated posture support | Contoured slightly concave seat pan and angled mid-height backrest optimized for upright meeting and desk use, with no recline or tilt mechanism visible | |
| Floor protection | Soft nylon glides prevent scratching on hard wood, tile, and low-pile carpet flooring without requiring additional chair mats | |
| Cleaning and maintenance | Smooth non-porous PU upholstery allows wipe-clean disinfection with 75% alcohol or mild detergent in 30 seconds with no liquid absorption | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference carton dimensions (L×W×H) | 900 × 680 × 550 mm | |
|---|---|---|
| Reference gross weight per carton | 27 kg | |
| Reference carton volume (CBM) | 0.34 CBM | |
| 20ft GP container loading quantity | 170 units | |
| 40ft HQ container loading quantity | 410 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set |
Recommended spaces / users / usage modes
| Corporate conference and meeting rooms | Provides professional cohesive seating for boardrooms, team meeting spaces, and client presentation areas with consistent modern styling and swivel function for easy interaction | |
|---|---|---|
| Reception and guest waiting areas | Polished light blue upholstery and chrome base create a welcoming professional appearance for lobbies, banking halls, automotive 4S dealerships, and service counters | |
| Home office and private study spaces | Compact footprint and sleek modern design suit residential workspaces, with height adjustment to pair with standard 760 mm height office desks | |
| Negotiation and breakout spaces | 360-degree swivel and stationary glide base support casual collaboration and client discussion without unwanted rolling movement across hard flooring | |
| Executive office guest seating | Matching styling can be used as visitor seating opposite executive desks, coordinating with leather desk sets and chrome office hardware | |
| Training and educational spaces | Fixed arm support and upright posture design suits 8 hour training sessions in corporate academies and vocational education rooms, with easy-wipe upholstery for high-turnover use | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | European standard for office furniture: office work chairs, defining dimensional, safety, strength, and durability requirements for commercial office seating | |
|---|---|---|
| EN 1022:2018 | European standard for furniture seating: determination of stability, applicable for verifying tip resistance of four-star base swivel chairs | |
| EN 14465:2003 | European standard for furniture upholstery fabrics, specifying abrasion, colorfastness, and tear strength requirements for contract seating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | North American standard for office chairs: general purpose, defining static load, durability, stability, and safety test requirements for commercial seating products |
|---|
Standards applicable to China-market projects
| GB/T 10357.3-2013 | Test standard for mechanical properties of furniture: chairs and stools, covering static load, impact, and fatigue testing for office seating, recommended as minimum acceptance criterion for procurement | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to the internal plywood structural frame dimensional stability and formaldehyde emission limits | |
| GB/T 19995.2-2005 | Test method for furniture hardware: gas springs for seating, specifying durability and load performance for height adjustment cylinders |
This product must meet the following technical requirements: 1. GB/T 10357.3-2013: Test standard for mechanical properties of furniture: chairs and stools, covering static load, impact, and fatigue testing for office seating, recommended as minimum acceptance criterion for procurement; 2. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to the internal plywood structural frame dimensional stability and formaldehyde emission limits; 3. GB/T 19995.2-2005: Test method for furniture hardware: gas springs for seating, specifying durability and load performance for height adjustment cylinders; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
