| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1200 x 400 x 850 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Top planter static load capacity | 30 kg | |
|---|---|---|
| Product net weight | 42 kg | |
| Planter trough soil capacity | 24 L | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet carcass | 18mm thick E1 grade melamine-faced particleboard | |
|---|---|---|
| Door panels | 18mm thick textured vertical-grain melamine-faced MDF | |
| Planter trough interior | Moisture-resistant laminated engineered wood | |
| Edge banding | 2mm thick PVC edge banding | |
| Door hardware | Concealed soft-close cabinet hinges | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Enclosed storage access | Three hinged doors swing outward to access internal shelved storage | |
|---|---|---|
| Integrated planter function | Recessed top trough holds decorative plants to serve as a green space divider | |
| Storage configuration | Single fixed mid-height shelf splits internal space into two storage tiers | |
| Space divider function | Low profile allows open sightlines above while creating visual zone separation |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 1280 x 460 x 120 mm | |
| Gross shipping weight | 47 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open office space division | Placed between workstation clusters to define zones while adding greenery | |
|---|---|---|
| Waiting area and lounge storage | Positioned against walls or between seating groups for storage and decorative planting |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
