PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1600 × 450 × 950 mm
Overall cabinet size	1600 x 450 x 950 mm
Carcass Panel Thickness	25 mm
Back Panel Thickness	9 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net cabinet weight	68 kg
Countertop distributed load	40 kg
Open shelf distributed load	20 kg
Interior adjustable shelf load	15 kg per shelf
Storage volume	0.46 m3
Recommended users	1 to 4 people
Door cycle acceptance	50000 cycles
Hinge static capacity	35 kg per pair
Shelf Distributed Load	30 kg/shelf
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Main carcass	18 mm engineered-wood panels with warm grey painted exterior and dark interior backing
Countertop	40 mm walnut-brown laminate or veneered wood-composite slab with sealed edge
Door fronts	Walnut-toned engineered-wood doors with vertical fluted profile and matched grain direction
Outer frame	Warm grey painted side panels, rounded corner posts and matching plinth
Open shelf board	Grey laminate shelf and back panel sized for cups, canisters and trays
Hardware	Concealed hinges, shelf supports and door pulls integrated into the fluted face

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Beverage preparation zone	900 mm-high countertop supports kettles, coffee servers and trays, with a 120 mm rear upstand limiting spills
Open display storage	820 mm-wide open bay provides a 280 mm-high compartment for frequently used cups and canisters
Enclosed pantry storage	Right 690 mm-wide tall door and two lower doors conceal dry goods, utensils and cleaning supplies
Adjustable interior shelving	Use 18 mm shelves on 32 mm-grid supports, with 15 kg per shelf and minimum five shelf heights

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Packed carton size	1680 x 520 x 260 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Office pantry or tea point	Suits a compact beverage station where kettles, cups, dry goods and trays are used daily by staff
Meeting-area breakout zone	Provides display storage and hidden pantry storage beside meeting rooms or lounges

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · PCB-1600-WF

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · PCB-1600-WF

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · PCB-1600-WFOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Walnut Fluted-Door Pantry Cabinet with Open Beverage Shelf, model PCB-1600-WF, is a floor-standing pantry unit with a modern two-tone appearance. Its walnut-toned fluted doors provide a textured focal point, while the warm grey painted side panels, rounded corner posts and matching plinth create a softer architectural frame. The layout combines an open beverage bay on one side with enclosed storage behind one tall right-hand door and two lower doors, balancing accessible display space with concealed pantry storage. Integrated pulls in the fluted door faces and concealed hinges maintain a clean visual line. The cabinet is supplied unbranded. Its overall size is 1600 x 450 x 950 mm. Construction uses an engineered-wood carcass with a warm grey painted exterior and dark interior backing. The main carcass panels are 18 mm, while the product specification lists carcass panel thickness at 25 mm, a 9 mm back panel, 22 mm door and drawer fronts, and 25 mm shelves. The walnut tone is achieved with walnut-veneer engineered wood and matched grain direction on the doors. A 40 mm walnut-brown laminate or veneered wood-composite countertop with a sealed edge tops the beverage preparation area, and the open bay uses a grey laminate shelf and back panel. The countertop is 900 mm high and includes a 120 mm rear upstand to limit spills. It supports kettles, coffee servers and trays in daily beverage service. The open display bay is 820 mm wide with a 280 mm-high compartment, sized for frequently used cups, canisters and trays. Behind the doors, adjustable 18 mm shelves sit on 32 mm-grid supports and offer at least five shelf heights for dry goods, utensils and cleaning supplies. Rated distributed loads are 40 kg for the countertop, 20 kg for the open shelf and 15 kg per adjustable interior shelf. Total storage volume is 0.46 cubic metres, and the doors are accepted through 50,000 opening cycles. The cabinet is well suited to compact office pantries and tea points used daily by staff, as well as breakout areas beside meeting rooms or lounges where open display and hidden storage are both required. It is also appropriate for residential beverage or utility zones where a coordinated, furniture-style pantry is desired. The recommended user group is one to four people. Procurement planning should account for the 68 kg cabinet weight and the floor-standing footprint. Packaging references indicate a set delivered in multiple cartons, with logistics information varying between a two-carton presentation and a three-carton carcass split; the quoted packed dimensions include 1680 x 520 x 260 mm and 2100 x 700 x 350 mm per carton, with packaged gross weight up to 100 kg and packaging volume up to 0.65 cubic metres per set. Buyers should confirm delivery configuration, access routes, assembly responsibility and shelf arrangement before installation. Reference assembly time is 40 minutes per set.

Walnut Fluted-Door Pantry Cabinet with Open Beverage Shelf Specifications
