Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet dimensions | 1800 x 450 x 800 mm | |
|---|---|---|
| Upper open shelf section height | 270 mm | |
| Individual upper open cubby width | 870 mm | |
| Open shelf interior depth | 420 mm | |
| Lower closed storage section height | 490 mm | |
| Accent trim thickness | 20 mm | |
| Support foot height | 40 mm | |
| Side panel thickness | 18 mm | |
| Vertical divider thickness | 18 mm | |
| Sliding door panel thickness | 18 mm | |
| Adjustable interior shelf spacing | 32 mm increments | |
| Floor clearance under cabinet | 30 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Uniformly distributed load per shelf | 40 kg | |
|---|---|---|
| Total cabinet static load capacity | 160 kg | |
| Net weight | 58 kg | |
| Door lock cycle rating | 10000 operations | |
| Commercial warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main cabinet panels | 18mm E0 grade melamine-faced engineered wood | |
|---|---|---|
| Accent trim | 20mm melamine panel in warm brown finish | |
| Sliding door tracks | Cold-rolled steel with powder-coated finish | |
| Lock cylinders | Zinc alloy keyed cam locks | |
| Support feet | Injection-molded polypropylene, light grey finish | |
| Back panel | 3mm hardboard with matching finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper display storage | Two equal open cubbies for books, decor and frequently accessed items | |
|---|---|---|
| Lower concealed storage | Three sliding lockable doors enclosing adjustable interior shelves | |
| Adjustable shelving | Removable shelves repositionable in 32mm increments | |
| Secure locking | Keyed locks restrict access to confidential documents and stored materials |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office side storage | Placed along workstation partitions or walkways for shared supply and file storage | |
|---|---|---|
| Executive office auxiliary storage | Positioned adjacent to executive desks for display items and locked document storage |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for stability and load testing | |
|---|---|---|
| EN 14073-3:2004 | Office storage furniture stability and structural strength test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Standard for office storage units, applicable for load, durability and stability validation |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel strength and dimensional stability checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, mandatory minimum E1 grade acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel strength and dimensional stability checks; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, mandatory minimum E1 grade acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
