Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet dimensions | 1500 x 400 x 840 mm | |
|---|---|---|
| Top surface thickness | 18 mm | |
| Side panel thickness | 15 mm | |
| Back panel thickness | 3 mm | |
| Left closed cabinet compartment width | 500 mm | |
| Right closed cabinet compartment width | 500 mm | |
| Central open storage section width | 500 mm | |
| Plinth base height | 100 mm | |
| Upper open shelf clearance height | 300 mm | |
| Lower open shelf clearance height | 320 mm | |
| Open shelf depth | 370 mm | |
| Door panel thickness | 18 mm | |
| Corner radius on left edge | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Top surface static load capacity | 110 kg | |
|---|---|---|
| Net product weight | 48 kg | |
| Door hinge cycle rating | 50000 open/close cycles | |
| Recommended maximum evenly distributed total load | 220 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet carcase | E1 grade 15mm particleboard with matte taupe laminate finish | |
|---|---|---|
| Door panels | 18mm MDF with scratch-resistant matte lacquer coating, handleless push-to-open design | |
| Top surface | 18mm substrate with stone-look heat-resistant laminate, eased rounded edges | |
| Accent trim below top | Warm walnut-toned wood veneer wrapped MDF accent strip | |
| Open shelf panels | 15mm engineered wood with matching matte taupe finish, fixed central divider | |
| Plinth base | 15mm engineered wood with matching finish, recessed 20mm from front face |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door operation | Push-to-open handleless mechanism with soft-close 110-degree hinges | |
|---|---|---|
| Closed cabinet storage | Each side cabinet includes one adjustable height shelf with 5 position options | |
| Open display storage | Central section divided by one fixed shelf into two open display compartments | |
| Safety design | Rounded front and side corners eliminate sharp edge impact risks |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Dining room buffet | Place against dining wall to store tableware and display decor, with 840mm height aligned to dining sightlines | |
|---|---|---|
| Living room console | Position behind sofa or along living wall for media accessory storage and curated item display |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements and test methods | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety for domestic storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability and finish durability | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability and finish durability; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
