Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1200 x 400 x 800 mm | |
|---|---|---|
| Top overhang | 20 mm front and sides | |
| Left bay width | 600 mm | |
| Upper drawer internal height | 150 mm | |
| Sliding door panel height | 500 mm | |
| Right open bay width | 600 mm | |
| Upper open shelf clearance | 280 mm | |
| Lower open shelf clearance | 280 mm | |
| Open shelf depth | 380 mm | |
| Plinth base height | 70 mm | |
| Cabinet side panel thickness | 18 mm | |
| Top panel thickness | 25 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Top surface static load capacity | 68 kg | |
|---|---|---|
| Net product weight | 50 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Sliding door glide cycle rating | 30000 open/close cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet carcass | 18mm thick particleboard with dark grey melamine laminate | |
|---|---|---|
| Top surface | 25mm thick engineered wood with light oak-effect melamine veneer | |
| Drawer and door panels | 15mm thick MDF with matching dark grey matte laminate finish | |
| Open shelf panels | 18mm thick particleboard with dark grey melamine finish | |
| Drawer slides | Zinc-plated cold-rolled steel 3/4 extension telescoping glides | |
| Sliding door tracks | Powder-coated steel track with nylon roller glides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper left drawer | Smooth-gliding shallow storage for cutlery, napkins, and small household items | |
|---|---|---|
| Sliding door compartment | Single-panel sliding door conceals lower left enclosed storage with one adjustable shelf | |
| Right open display shelves | Two fixed-tier open shelves for decor, books, and frequently accessed items | |
| Plinth base support | Full-width solid plinth provides stable floor contact with no adjustable feet |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Dining room buffet storage | Placed against dining walls to store tableware, linens, and display decor | |
|---|---|---|
| Living room media/credenza use | Positioned under wall-mounted TVs to hold media devices and accessories |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic and kitchen storage furniture | |
|---|---|---|
| EN 312:2010 | Particleboard performance specifications for load-bearing furniture applications |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
