Two-Tone Fluted Walnut and Black Freestanding Storage Cabinet with Mixed Open and Closed Storage (model SC-FW-BK-1600) is listed under Room Divider Planter Cabinet, with overall dimensions of 1600 × 400 × 1200 mm and main material of Particle‑board (PB). Load capacity: 25 kg. Certifications: Modern,two-tone,Freestanding,Mixed,open/closed,storage,Fluted,wood,door,Black,frame. This page consolidates 6 groups of specifications and GB / EN standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet dimensions | 1600 x 400 x 1200 mm | |
|---|---|---|
| Left single-door compartment width | 400 mm | |
| Right double-door compartment width | 800 mm | |
| Open shelf middle section width | 400 mm | |
| Open shelf vertical spacing (middle section) | 200 mm | |
| Door panel thickness | 18 mm | |
| Shelf panel thickness | 20 mm | |
| Carcass side/back panel thickness | 15 mm | |
| Base foot glide height | 20 mm | |
| Edge band thickness | 2 mm | |
| Upper right open cubby height | 400 mm | |
| Lower open cubby height (middle section) | 200 mm | |
| Interior closed compartment depth | 370 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 70 kg | |
|---|---|---|
| Static load per adjustable shelf | 25 kg | |
| Top surface static load capacity | 50 kg | |
| Recommended maximum total storage load | 200 kg | |
| Door hinge open angle | 110 degrees | |
| Hinge cycle durability | 80000 cycles | |
| Product warranty period | 3 years | |
| Available finish options | 2 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Door panels | Walnut-tone fluted engineered wood with matte wood grain veneer | |
|---|---|---|
| Carcass frame and dividers | Matte black laminated high-density particleboard | |
| Open shelf panels | Black laminated engineered wood, 20mm thick | |
| Hardware (handles, hinges) | Matte black finished steel | |
| Base glides | Black nylon adjustable leveling feet | |
| Edge banding | 2mm thick matte black PVC, applied to all exposed panel edges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Closed door storage | Three total hinged doors (1 left, 2 right) enclosing concealed storage compartments | |
|---|---|---|
| Adjustable open shelving | Four horizontal middle shelves support repositioning for variable item heights | |
| Open display storage | Two additional open cubbies (lower middle, upper right) for frequently accessed or displayed items | |
| Anti-tip safety | Two wall-mounted anti-tip connectors included to secure cabinet to wall studs |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living space | Suitable for living room display and concealed storage of media accessories, books and decor | |
|---|---|---|
| Office storage area | Applicable for office breakout areas or open work zones to store documents, supplies and display materials |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard performance requirements, applicable to structural panel load verification | |
|---|---|---|
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage furniture | |
| EN 717-1:2004 | Formaldehyde emission testing for wood-based panels, for indoor use compliance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance | |
| GB/T 4897.3-2015 | Particleboard specifications for furniture use, applicable to carcass panel quality verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance; 3. GB/T 4897.3-2015: Particleboard specifications for furniture use, applicable to carcass panel quality verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
