PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3000 × 350 × 1200 mm
Carcass Panel Thickness	25 mm
Back Panel Thickness	9 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Product net weight	95 kg
Distributed top surface load	60 kg
Single-cubby shelf load	10 kg
Total evenly distributed storage load	240 kg
Vertical divider spacing stability	300 mm nominal
Floor contact type	Continuous plinth support
Anti-tip wall anchoring requirement	2 metal brackets, 50 kg pull rating each
Recommended shelf deflection limit	Span/200 under rated load
Color and finish options	1 visible walnut-tone finish with matte gray accents
Warranty target	5 years structural, 2 years finish and hardware

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Primary case panels	Walnut-look wood-based board with matching edge banding on shelves, dividers and sides
Back panel	Matching dark brown board backing each cubby
Accent trims	Matte dark gray laminate or painted composite panels on upper fascia and plinth
Top surface	Flat wood-look panel with square edge detail
Internal joinery	Panel-to-panel carcass construction using dowels, confirmat connectors or minifix fittings
Fasteners and anti-tip hardware	Steel cam locks, wood dowels and wall-anchor brackets recommended

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Open display storage	30 front-access cubbies provide separate compartments for books, packaged goods, ceramics and decorative boxes
Horizontal top display zone	A 3000 mm continuous top supports framed objects, art pieces or low decorative arrangements above the gray fascia
Floor-standing installation	The cabinet rests on a continuous gray plinth and should be wall-anchored before loading upper cubbies
Cable-free display configuration	No visible power module, cable grommet, lighting switch or internal wireway is present

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Carton dimensions	3060 x 400 x 180 mm for main panels, plus 1220 x 400 x 160 mm for shelf packs
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Lounge and reception display	Place along a waiting-area wall to organize publications, art objects and branded merchandise in individually visible cubbies
Library, tea room or lifestyle retail use	Use as a 3 m open display wall for books, packaged goods and ceramics where front-facing browsing is needed

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 16121 storage furniture safety requirements	Apply to strength, durability, stability and safe operation of non-domestic storage furniture
EN 16122 storage furniture test methods	Applicable standards and test results require confirmation
EN 717-1 formaldehyde release	Specify chamber-based formaldehyde emission verification for board materials
EN 12720 surface resistance to cold liquids	Use for evaluating the wood-look finish against beverages and cleaning products

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324 dimensional and structural verification	Apply to wooden cabinets for dimensional accuracy, edge quality, stability and load-bearing acceptance
GB/T 3325 physical and chemical surface testing	Use for resistance to abrasion, stains, moisture and color variation on wood-based furniture surfaces
GB/T 39600 formaldehyde emission grading	Specify E1 or a stricter project-approved emission class for all wood-based panels
GB 28007 furniture safety guidance	Use for stability, accessible edges and hardware safety verification where children may use the space

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324 dimensional and structural verification: Apply to wooden cabinets for dimensional accuracy, edge quality, stability and load-bearing acceptance;
2. GB/T 3325 physical and chemical surface testing: Use for resistance to abrasion, stains, moisture and color variation on wood-based furniture surfaces;
3. GB/T 39600 formaldehyde emission grading: Specify E1 or a stricter project-approved emission class for all wood-based panels;
4. GB 28007 furniture safety guidance: Use for stability, accessible edges and hardware safety verification where children may use the space;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OBC-30C-WAL-3000

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OBC-30C-WAL-3000

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OBC-30C-WAL-3000Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Walnut-Finish Open Cubby Display Bookcase is a low, horizontal open bookcase designed for visible storage and display. Its front elevation is organized as a regular open-grid arrangement with 30 separate cubbies, giving the piece a structured retail-style appearance while retaining the warmth of a walnut-look wood finish. Matching dark brown back panels define each compartment, while matte dark gray accent trims on the upper fascia and plinth provide a contrasting frame. A flat, wood-look top with square edge detail creates a continuous display zone above the cubbies, and the cabinet stands on a continuous gray plinth rather than separate legs. Its overall dimensions are 3000 x 350 x 1200 mm, with 25 mm-thick main case panels and shelves, a 9 mm back panel, and 22 mm door or drawer front thickness noted within the specification. The case is built from walnut-look wood-based board with matching edge banding on the shelves, dividers, and sides. Internal construction uses panel-to-panel joinery with dowels, confirmat connectors, or minifix fittings, together with steel cam locks and wood dowels. The unit weighs 95 kg and is intended for floor-standing installation supported across the full plinth. Functionally, the bookcase offers 30 front-access compartments suitable for books, packaged goods, ceramics, decorative boxes, publications, art objects, and branded merchandise. The wide top is suited to framed objects, art pieces, or low decorative arrangements. With no power module, cable grommet, lighting switch, or internal wireway, the configuration keeps the visual presentation clean and cable-free. Rated loads include 60 kg distributed across the top, 10 kg for a single cubby shelf, and 240 kg for total evenly distributed storage. The design is appropriate for commercial interiors such as lounges, reception and waiting areas, libraries, tea rooms, and lifestyle retail spaces, particularly where a 3 m open display wall supports front-facing browsing. It can also serve residential living rooms or studies where extensive open storage is desired. Procurement planning should account for the unit’s scale and weight, wall-anchoring requirement, and delivery format. The bookcase must be secured with two metal wall-anchor brackets rated for 50 kg pull each before upper cubbies are loaded. Packaging information includes alternative supplied logistics records showing two cartons and reference split-carcass packing details, so buyers should confirm the exact packing configuration, delivery access, placement length, floor protection, and assembly arrangements before purchase. A reference assembly time of 40 minutes per set is provided.

Walnut-Finish Open Cubby Display Bookcase with 30 Compartments Specifications
