Contemporary Sideboard with Drawer, Door and Twin Smoked-Glass Display Compartments (model SB-CRM1600-2GD1) is listed under Room Divider Planter Cabinet. Dimensions: 1600 × 420 × 850 mm. Materials: 30 mm engineered-wood substrate with dark smooth decorative laminate and champagne-gone metal edge trim. Load capacity: 60 kg. Product Features: Contemporary,style,mixed,closed,and,glazed,storage,low,sideboard,form,illuminated,display. This page consolidates 6 groups of specifications, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | XIANGSHI | Model | SB-CRM1600-2GD1 |
| Overall dimensions (W × D × H) | 1600 × 420 × 850 mm | Primary Component Thickness | 40 mm according to load-bearing role |
| Hardware / Moving-part Clearance | 5 mm operating clearance | Top distributed static load | 60 kg |
| Drawer static load | 15 kg | Lower cabinet shelf load | 20 kg |
| Each display shelf load | 10 kg per level | Door hinge durability | 50,000 opening cycles |
| Drawer runner durability | 50,000 opening cycles | Glass door impact safety | Tempered safety glass required for each display door |
| Stability under eccentric load | No overturning when a 20 kg vertical load is applied 50 mm from the front edge | LED operating life | 30,000 hours |
| Reference Static Load | 150 kg depending on category | Top panel | 30 mm engineered-wood substrate with dark smooth decorative laminate and champagne-gone metal edge trim |
| Carcase body | 18 mm moisture-resistant engineered-wood panels with dark open-grain wood veneer or veneer-effect finish | Drawer front | 18 mm engineered-wood substrate with warm off-white matte polyurethane lacquer and rounded lower corner |
| Lower door front | 18 mm engineered-wood substrate with warm off-white matte polyurethane lacquer in a framed slab design | Side panels | 30 mm engineered-wood panels with warm off-white lacquer and fine vertical fluted surface detail |
| Display doors | 5 mm smoked tempered glass set in narrow champagne-gold metal door frames | Top drawer storage | One horizontally aligned drawer opens on full-extension runners with a 450 mm travel and supports 15 kg of tableware or documents |
| Lower concealed storage | One hinged cabinet door opens 110 degrees and provides a 500 mm high enclosed compartment with one removable shelf | Twin display storage | Two independently hinged smoked-glass doors each provide two display levels and a 315 mm shelf clearance |
| Soft-close operation | Door hinges and drawer runner include damping to close silently within the final 45 mm of travel | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Packaging Volume | 0.8 m³/set |
| Reference Packaged Gross Weight | 120 kg/set | Dining room or breakfast area | Place against a wall for tableware, wine accessories and display objects, using the 60 kg top load for serving trays and lamps. |
| Living room media wall side position | Use beside a sofa or low TV wall for books, ornaments and concealed clutter, without classifying the unit as a media console. | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 420 × 850 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Top distributed static load | 60 kg | |
|---|---|---|
| Drawer static load | 15 kg | |
| Lower cabinet shelf load | 20 kg | |
| Each display shelf load | 10 kg per level | |
| Door hinge durability | 50,000 opening cycles | |
| Drawer runner durability | 50,000 opening cycles | |
| Glass door impact safety | Tempered safety glass required for each display door | |
| Stability under eccentric load | No overturning when a 20 kg vertical load is applied 50 mm from the front edge | |
| LED operating life | 30,000 hours | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top panel | 30 mm engineered-wood substrate with dark smooth decorative laminate and champagne-gone metal edge trim | |
|---|---|---|
| Carcase body | 18 mm moisture-resistant engineered-wood panels with dark open-grain wood veneer or veneer-effect finish | |
| Drawer front | 18 mm engineered-wood substrate with warm off-white matte polyurethane lacquer and rounded lower corner | |
| Lower door front | 18 mm engineered-wood substrate with warm off-white matte polyurethane lacquer in a framed slab design | |
| Side panels | 30 mm engineered-wood panels with warm off-white lacquer and fine vertical fluted surface detail | |
| Display doors | 5 mm smoked tempered glass set in narrow champagne-gold metal door frames |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Top drawer storage | One horizontally aligned drawer opens on full-extension runners with a 450 mm travel and supports 15 kg of tableware or documents | |
|---|---|---|
| Lower concealed storage | One hinged cabinet door opens 110 degrees and provides a 500 mm high enclosed compartment with one removable shelf | |
| Twin display storage | Two independently hinged smoked-glass doors each provide two display levels and a 315 mm shelf clearance | |
| Soft-close operation | Door hinges and drawer runner include damping to close silently within the final 45 mm of travel |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Dining room or breakfast area | Place against a wall for tableware, wine accessories and display objects, using the 60 kg top load for serving trays and lamps. | |
|---|---|---|
| Living room media wall side position | Use beside a sofa or low TV wall for books, ornaments and concealed clutter, without classifying the unit as a media console. |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
