Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 1829 x 610 x 737 mm | |
|---|---|---|
| top panel thickness | 25 mm | |
| single door width | 600 mm | |
| support foot height | 50 mm | |
| floor clearance under cabinet | 50 mm | |
| grey top edge trim thickness | 20 mm | |
| internal storage compartment width per door | 580 mm | |
| internal storage depth | 580 mm | |
| internal clear storage height | 642 mm | |
| adjustable shelf thickness | 18 mm | |
| door panel thickness | 18 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| top surface static load capacity | 50 kg | |
|---|---|---|
| product net weight | 101 kg | |
| keyed lock cycle durability | 10000 operations | |
| door hinge open angle | 110 degrees | |
| available finish variants | 8 | |
| warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| cabinet body and doors | 18mm melamine-faced MDF/particleboard with light oak vertical wood grain | |
|---|---|---|
| top panel | 25mm melamine-faced engineered wood with light grey contrasting edge trim | |
| support feet | Injection-molded polypropylene cylindrical feet with non-scuff base pads | |
| internal shelving | 18mm melamine-faced engineered wood adjustable shelves with metal shelf pins | |
| hardware | Zinc alloy keyed cam locks, steel concealed hinges, steel shelf supports | |
| edge banding | 2mm thick PVC edge banding on all exposed panel edges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| locking system | Two keyed cam locks securing middle and right compartments, left door locked via middle door interlock | |
|---|---|---|
| door operation | Three hinged doors with 110-degree opening range, left door opens first for access to full interior | |
| interior shelving | Three adjustable shelves per compartment, repositionable in 32mm increments to accommodate mixed storage heights | |
| floor protection | Elevated 50mm above floor on non-marking plastic feet to prevent floor scuffing and enable easy floor cleaning |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| under-window office storage | Fits standard 737mm low height for placement below office windows without blocking natural light | |
|---|---|---|
| behind-desk credenza storage | Placed behind executive desks for secure document, supply and personal item storage with wide flat top |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for structural stability and load performance | |
|---|---|---|
| EN 312:2010 | Particleboard specifications, applicable for engineered wood panel structural performance | |
| EN 13722:2004 | Furniture test methods for strength and durability of storage units, applicable for cyclic load testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture standard, applicable for vertical/horizontal load and stability testing for office use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel dimensional tolerances and finish quality | |
|---|---|---|
| GB/T 4897-2015 | Particleboard standard, applicable for structural panel material performance verification | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel dimensional tolerances and finish quality; 2. GB/T 4897-2015: Particleboard standard, applicable for structural panel material performance verification; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
