Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint | 800 x 800 x 400 mm | |
|---|---|---|
| Large table top | 800 mm diameter x 25 mm thick | |
| Large table height | 400 mm | |
| Large drum base | 700 mm diameter x 375 mm high | |
| Small table top | 600 mm diameter x 10 mm thick | |
| Small table height | 300 mm | |
| Small pedestal base | 280 mm diameter x 260 mm high | |
| Curved drawer front | 650 mm arc width x 345 mm high x 20 mm thick | |
| Drawer interior | 345 x 310 x 95 mm | |
| Nesting clearance under large top | 305 mm vertical clearance and 250 mm entry depth | |
| Floor contact diameter | 700 mm large base and 280 mm small base | |
| Top usable service area | 0.50 square meters on large top and 0.28 square meters on small top | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Large table distributed load capacity | 68 kg | |
|---|---|---|
| Set net weight reference | 30 kg | |
| Drawer storage volume | 10 liters | |
| Drawer recommended contents load | 8 kg | |
| Static stability verification | 10 kg lateral top-edge load without tipping | |
| Floor pressure load | 0.04 kg per square centimeter under rated 68 kg load | |
| Recommended users at one time | 4 adults | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large table top | White glossy marble-veined engineered board or sintered-stone-look panel, 25 mm thick | |
|---|---|---|
| Black drum carcass | Black wood-composite cylindrical cabinet with matte or low-sheen outer wrap | |
| Drawer front | Curved black manufactured-wood panel with rounded vertical edge and smooth exterior | |
| Drawer interior | Light natural-toned wood or wood-composite liner with visible grain and flat base | |
| Small table top | Amber-tinted transparent glass circular top with polished edge | |
| Small pedestal | Black cylindrical manufactured column with textured upper cap and circular footplate | |
| Base finish | Black coated or laminated exterior finish on both pedestal forms | |
| Drawer hardware | Side or under-mounted slides sized for the curved pull-out tray | |
| Floor protection | Continuous circular foot ring or base plate intended to distribute load on rugs and hard floors | |
| Panel edge banding | Sealed black edge treatment around curved drawer and drum panels | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Nesting layout | The 600 mm table offsets beneath the 800 mm top to reduce occupied floor space | |
|---|---|---|
| Independent use | The smaller amber table can be pulled out beside a sofa as a drinks or accent table | |
| Curved drawer storage | The semicircular drawer pulls outward from the drum and stores magazines, remotes, and small living-room items | |
| Drawer access limit | The drawer should be opened while the nested table is offset to avoid interference with the pedestal | |
| Serving surface | The large circular top supports trays, glasses, flowers, books, and decor at sofa-seat height | |
| Low-profile support | Both tables use closed pedestal drums rather than four legs, creating open surrounding foot space | |
| Rug-friendly placement | The circular foot profiles sit on area rugs without protruding legs or sharp corners | |
| Non-adjustable height | Both tabletops are fixed-height surfaces with no lift, rotation, or powered mechanism | |
| Floor repositioning | Each table is lifted for repositioning; no casters or braking devices are present | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Modern living room | Place in front of a three-seat sofa for drinks, books, decor, and occasional trays | |
|---|---|---|
| Small apartment lounge | Use the nested offset to save floor space while retaining two separate surfaces | |
| Lounge or reception seating area | Deploy beside modular seating as an amber-glass accent table and larger central table | |
| Home media or relaxation zone | Use for magazines and remote controls in the curved drawer while keeping the top clear | |
| Hotel or serviced-apartment guest room | Specify as a coordinated decorative pair where a durable non-sharp-edge table set is required | |
| Showroom or model-home styling | Pair with neutral rugs and stone, wood, or leather furniture to highlight mixed materials |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
