Automatic mm / inch conversion · Core engineering specifications
| Overall cabinet size | 2200 x 400 x 400 mm | |
|---|---|---|
| Open left cubby width | 360 mm | |
| Open cubby depth | 360 mm | |
| Open cubby interior height | 220 mm | |
| Individual drawer front width | 560 mm | |
| Drawer interior width | 520 mm | |
| Drawer interior depth | 350 mm ││ Based on 400 mm console depth minus front, rear and slide clearance | |
| Drawer interior height | 170 mm | |
| Top panel thickness | 18 mm | |
| Carcass panel thickness | 18 mm | |
| Back panel thickness | 3 mm | |
| Rounded right-end radius | 200 mm | |
| Plinth recess height | 50 mm | |
| Right display top height difference | 20 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Net weight | 38 kg | |
|---|---|---|
| Distributed top load | 50 kg | |
| Fixed cubby shelf load | 20 kg | |
| Per-drawer load | 15 kg | |
| Maximum television size | 85 in | |
| Recommended wall clearance | 50 mm | |
| Drawer slide durability | 50,000 cycles | |
| Color options | 2 visible finishes | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top panel | Engineered wood panel with smooth matte cream laminate or painted finish | |
|---|---|---|
| Drawer fronts | Engineered wood panels in taupe-brown smooth matte finish with handleless faces | |
| Carcass sides and dividers | 18 mm engineered wood board with edge banding and matching cream finish | |
| Back panel | 3 mm MDF or hardboard back set into a rear groove | |
| Open cubby surfaces | Laminated engineered wood interior with taupe side and light-colored base | |
| Rounded right end | Bent or curved engineered-wood fascia with continuous taupe-brown surface | |
| Recessed plinth | Engineered wood base frame set back from front and side faces | |
| Drawer slides | Side-mounted metal slides with concealed runners behind handleless fronts | |
| Protective surface | Matte abrasion-resistant laminated or painted surface | |
| Assembly hardware | Cam-lock connectors, screws and corner dowels for knockdown panel construction | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Three-drawer storage | Three side-by-side handleless drawers provide 520 x 350 x 170 mm internal media storage each | |
|---|---|---|
| Left open equipment bay | One fixed 360 x 360 x 220 mm cubby holds a router, set-top box or display objects | |
| Handleless drawer access | Drawers are opened by gripping the recessed upper or side edge of each flat front | |
| Right display zone | Raised rounded right platform supports bottles, decor or a small media accessory with 20 mm visual separation | |
| Low-profile wall placement | Recessed plinth and 400 mm height place the television near floor level while maintaining a continuous front | |
| Cable routing provision | Specify a 60 mm rear cable opening centered behind the open cubby for router and television leads | |
| Ventilation for active devices | Provide 2500 mm2 rear ventilation area above heat-generating devices in the open bay | |
| Floor leveling | Use adjustable 10 mm feet concealed within the plinth to compensate for uneven floors | |
| Anti-tip restraint | Anchor the rear top rail to the wall with two metal restraint straps when loaded with a television | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room television wall | Place below a wall-mounted 75 in to 85 in television with soundbar and decor on the continuous top | |
|---|---|---|
| Apartment lounge | Use the open cubby for a router or streaming box and drawers for remote controls and cables | |
| Bedroom media area | Position beneath a wall-mounted screen while storing media accessories behind three low fronts | |
| Hotel or serviced-apartment suite | Specify for guestroom entertainment storage with durable matte panels and restrained visual profile | |
| Neutral two-tone interior | Coordinate with cream, taupe, walnut or warm beige furniture and soft rounded decor | |
| Display-led storage wall | Use the long top for framed artwork, a compact speaker, books and decorative objects |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
