Automatic mm / inch conversion · Core engineering specifications
| Carcass Panel Thickness | 25 mm | |
|---|---|---|
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Media console total net weight | 78 kg | |
|---|---|---|
| Stone top distributed static load | 60 kg | |
| Open AV shelf distributed load | 20 kg | |
| Drawer load per drawer | 8 kg | |
| Coffee table top distributed static load | 40 kg | |
| Suggested maximum TV screen size | 75 in | |
| Color options represented | 3 finishes | |
| Recommended warranty | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Console and table tops | White engineered stone or sintered-stone slab with subtle grey veining | |
|---|---|---|
| Beige drawer fronts | Matte taupe painted MDF or engineered-board panel with softened edges | |
| Dark end panels | Charcoal wood-grain veneer or melamine-faced engineered board | |
| Internal carcass | 18 mm moisture-resistant engineered board in black or dark grey finish | |
| Recessed plinth | Black powder-coated metal or rigid board base with matte finish | |
| Top support brackets | Dark grey metal side supports connecting the stone slab to the storage body | |
| Drawer runners | Side-mounted ball-bearing drawer slides with 45 mm nominal width | |
| Open shelf interior | Black matte laminate or painted interior board with horizontal shelf surface | |
| Edge treatment | Rounded soft-bound corners and continuous capsule-shaped profile | |
| Surface protection target | Scratch-resistant sealed stone top with heat-resistant rating to 65 degrees C | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Central AV compartment | Open-front shelf provides 170 mm usable height for a media player, router or sound device | |
|---|---|---|
| Drawer storage system | Two wide console drawers and one matching table drawer slide horizontally for concealed accessory storage | |
| Left end storage volume | Rounded left cabinet creates a vertical side compartment accessed through the front storage assembly | |
| Cable management opening | Circular 60 mm rear grommet position is represented by the visible round cable pass-through in the open bay | |
| Low-profile equipment layout | 450 mm console height keeps television sightlines low while retaining under-top storage | |
| Matching table open shelf | Coffee table combines an open display shelf with a lower curved drawer for remote controls and reading materials | |
| Soft-corner safety design | Both capsule-shaped pieces use fully rounded ends to reduce impact exposure in circulation areas | |
| Floor clearance | 15 mm recessed plinth gap permits floor cleaning while keeping the units visually floor-mounted | |
| Freestanding installation | Units are placed directly on a level floor without visible wall brackets; anti-tip fixings are advised if a TV is mounted above | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Modern living room | Place the console under a wall-mounted television and use the coffee table in the central seating zone | |
|---|---|---|
| Apartment lounge | Use the compact rounded set where circulation space is limited and sharp corners should be minimized | |
| Show flat or model home | Suitable for staged premium interiors because the stone-look top and mixed dark-taupe finish provide a high-contrast focal point | |
| Hotel suite | Specify for executive suites needing media storage plus a low table for reading materials and refreshments | |
| Reception waiting area | Use as a decorative media-and-table grouping where AV equipment is hidden but remote access is retained | |
| Floor condition | Install on level tile, wood or resilient flooring; add felt pads under the plinth to prevent abrasion |
EU Market Access Requirements* EN Standards
| Formaldehyde emission guidance | Recommended references: EN 13986 | |
|---|---|---|
| Surface durability guidance | EN 12720 and EN 12721 give cold-liquid and wet-heat resistance test methods for finished furniture surfaces | |
| Storage furniture safety | EN 14749 addresses safety and strength requirements for domestic and non-domestic storage units | |
| Safety glass guidance | EN 12150 applies only if the supplier substitutes tempered glass for the visible stone-look top |
Standards applicable to China-market projects
| Formaldehyde emission guidance | GB/T 39600 aldehyde emission classification applies to engineered-wood boards used in the carcass and fronts | |
|---|---|---|
| Furniture test guidance | GB/T 10357.5 provides a load-durability test reference for cabinet shelves and storage structures | |
| Surface furniture guidance | GB/T 3324 covers general wooden furniture dimensions, materials and inspection requirements |
This product must meet the following technical requirements: 1. Formaldehyde emission guidance: GB/T 39600 aldehyde emission classification applies to engineered-wood boards used in the carcass and fronts; 2. Furniture test guidance: GB/T 10357.5 provides a load-durability test reference for cabinet shelves and storage structures; 3. Surface furniture guidance: GB/T 3324 covers general wooden furniture dimensions, materials and inspection requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
