Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint when grouped | 1100 x 800 x 550 mm | |
|---|---|---|
| Large coffee table overall size | 800 mm diameter x 400 mm high | |
| Large tabletop thickness | 50 mm | |
| Large upper drum diameter | 800 mm | |
| Large lower pedestal diameter | 620 mm | |
| Large lower pedestal height | 180 mm | |
| Large table floor contact band | 620 mm diameter | |
| Small accent table overall size | 500 mm diameter x 550 mm high | |
| Small tabletop thickness | 60 mm | |
| Small pedestal diameter | 320 mm | |
| Small pedestal height | 490 mm | |
| Top overhang around small pedestal | 90 mm per side | |
| Height difference between tabletops | 150 mm | |
| Floor clearance beneath large top | 180 mm | |
| Floor clearance beneath small top | 490 mm | |
| Finished Top Thickness | 45 mm |
Net weight / load capacity / users / durability
| Large table distributed static load | 50 kg | |
|---|---|---|
| Small table distributed static load | 30 kg | |
| Concentrated edge load on large top | 20 kg at 100 mm from edge | |
| Concentrated edge load on small top | 15 kg at 80 mm from edge | |
| Set net weight | 38 kg | |
| Large table individual weight | 26 kg | |
| Small table individual weight | 12 kg | |
| Floor bearing pressure | 0.08 N/cm2 under 50 kg large-table load | |
| Recommended display objects per table | 6 objects or fewer | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large tabletop | Smooth white engineered-wood substrate with a sealed light surface | |
|---|---|---|
| Large outer finish | White low-sheen lacquered or laminated surface | |
| Large upper drum | Black wood-grain engineered-wood panels formed into a cylinder | |
| Large lower pedestal | Black wood-grain cylindrical base with horizontal stepped profile | |
| Small tabletop | Burgundy wood-composite substrate under a high-gloss coated surface | |
| Small pedestal | Matching burgundy cylindrical pedestal with high-gloss coating | |
| Internal support structure | Central wood or wood-composite blocking joining top and pedestal | |
| Base contact surface | Abrasion-resistant felt or protective pad ring recommended at 620 mm and 320 mm diameters | |
| Fasteners | Four M8 connector bolts per table with threaded metal inserts | |
| Finish system | Two-pack polyurethane or UV-cured lacquer with 0.20 mm cured topcoat | |
| Edge treatment | Sealed and coated circular edges with no exposed substrate | |
| Color composition | White large top, black wood-grain base, and burgundy accent table |
Adjustment / rotation / tilt / mobility / storage features
| Nesting layout | The smaller 550 mm table sits beside the 400 mm table without mechanical interlocks | |
|---|---|---|
| Separate use | Each table is freestanding and can be used independently as a coffee or accent table | |
| Storage configuration | No drawers, doors, shelves, or hinged compartments are provided | |
| Height adjustment | Fixed tabletops at 400 mm and 550 mm with no lift mechanism | |
| Extension function | Fixed 800 mm and 500 mm circular tops with no leaf or fold-out extension | |
| Mobility | Non-caster design intended to be lifted and repositioned manually | |
| Floor protection | Continuous drum bases distribute load and should use concealed anti-slip pads | |
| Surface use | Designed for drinks, books, decorative objects, and light display rather than seating or climbing | |
| Assembly method | Top attaches to pedestal with four M8 bolts through pre-drilled metal inserts | |
| Edge safety | Rounded circular profiles eliminate sharp external corners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Lounge seating area | Use the pair around modular sofas where sculptural forms and flexible surface space are needed | |
|---|---|---|
| Hotel guest room or suite | Use the low table for reading material and the burgundy table as a bedside or chair-side accent | |
| Showroom display | Pair the black-and-white table with the burgundy accent to demonstrate color blocking | |
| Small apartment living space | Group the tables tightly to reduce footprint, then separate them when entertaining | |
| Reception waiting zone | Use for magazines, cups, and decorative objects in a modern lounge setting | |
| Studio or creative office | Position beside lounge seating for informal meetings, magazines, and refreshments |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
