Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 900 × 900 × 750 mm | |
|---|---|---|
| Tabletop diameter | 900 mm | |
| Tabletop thickness | 25 mm | |
| Central support column diameter | 80 mm | |
| Round base diameter | 500 mm | |
| Round base thickness | 12 mm | |
| Under-table knee clearance height | 670 mm | |
| Under-table legroom radius | 380 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table net weight | 36 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 136 kg | |
| Recommended seating capacity | 2 people | |
| Base anti-tip stability load | 45 kg | |
| Sintered stone top heat resistance | 180 °C | |
| Powder coat finish scratch resistance | 3H pencil hardness | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 12mm sintered stone slab | |
|---|---|---|
| Tabletop edge treatment | Matte black finished eased edge | |
| Central support column | Powder-coated carbon steel tube | |
| Circular base plate | Powder-coated solid carbon steel disc | |
| Base floor protection | Non-slip EVA plastic rim | |
| Connection hardware | Zinc-plated steel M8 mounting bolts | |
| Surface finish (base/column) | Matte black textured powder coating | |
| Leveling adjustment feet | Injection-molded nylon adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly structure | Knock-down 3-part connection (top, column, base) | |
|---|---|---|
| Floor leveling | 4-point adjustable base glides, 10mm adjustment travel | |
| Seating access | 360-degree unobstructed legroom around central column | |
| Surface performance | Non-porous stain-resistant tabletop, suitable for hot dish placement | |
| Floor protection | Continuous EVA rim under base prevents hard floor scratches | |
| Surface maintenance | Seamless non-absorbent top allows wipe-clean care with household cleaners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small apartment dining nook | Compact 900mm footprint fits 2-person eating areas without wasted space | |
|---|---|---|
| Kitchen breakfast area | Standard dining height suits casual daily meal use next to kitchen counters | |
| Café and bistro seating | Durable matte finish holds up to light commercial daily patron use | |
| Open-plan living room accent | Minimalist all-black design complements modern contemporary interior schemes | |
| Small meeting breakout space | Stable pedestal base supports casual laptop use for 2-person discussions |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
