Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 800 x 750 mm | |
|---|---|---|
| Tabletop diameter | 800 mm | |
| Tabletop thickness | 23 mm | |
| Support column diameter | 80 mm | |
| Square base dimensions | 450 x 450 mm | |
| Base plate thickness | 8 mm | |
| Knee clearance height | 680 mm | |
| Floor clearance under base | 2 mm | |
| Edge radius of tabletop | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed load capacity | 200 kg | |
|---|---|---|
| Recommended seating capacity | 2 people | |
| Table net weight | 64 kg | |
| Surface scratch resistance rating | 6H | |
| Surface heat resistance | 1200 °C | |
| Tipping resistance load at edge | 30 kg | |
| Finish abrasion resistance cycles | 10000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop surface layer | 12 mm sintered stone, snow white matte finish | |
|---|---|---|
| Tabletop backing layer | 11 mm MDF reinforcing core | |
| Support column | 80 mm diameter carbon steel tube, matte black powder coat | |
| Square base plate | 8 mm thick carbon steel, matte black powder coat | |
| Base floor pads | 8 mm thick non-slip rubber pads | |
| Connection hardware | M10 steel hex bolts with locking washers | |
| Tabletop edge finish | Polished rounded edge, same white finish as top | |
| Column internal reinforcement | 2 mm steel welded mounting plates at top and bottom | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Height adjustment | Fixed 750 mm dining height, no adjustment mechanism | |
|---|---|---|
| Tabletop extension | Non-extendable fixed round top, no leaf mechanisms | |
| Rotating function | Fixed non-rotating top, rigidly mounted to central column | |
| Flooring protection | Integrated rubber base pads prevent scuffing on hard floors | |
| Cleaning functionality | Non-porous sintered stone surface resists staining, wipe-clean only | |
| Assembly requirement | Knock-down assembly connecting top, column and base with provided hardware | |
| Cable management | No integrated cable routing or cutouts present | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small apartment dining nook | Fits compact 2-person dining areas without occupying excess floor space | |
|---|---|---|
| Cafe and bistro seating | Suits commercial light-duty food service seating for two patrons | |
| Office reception waiting area | Functions as a side negotiation table for guest meetings | |
| Showroom and lounge areas | Pairs with armless upholstered dining chairs for display settings | |
| Balcony casual dining space | Suitable for covered outdoor balcony use with stable base | |
| Residential home office breakout area | Provides casual meeting space for two people away from workstations |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface resistance to cold liquids | |
| EN 1022:2005 | Furniture – Seating and tables – Determination of stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF backing layer | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard/MDF for furniture use, applies to core backing material | |
| GB/T 1732-1993 | Impact resistance test for paint films, applicable to powder coated metal parts |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF backing layer; 2. GB/T 4897.3-2003: Particleboard/MDF for furniture use, applies to core backing material; 3. GB/T 1732-1993: Impact resistance test for paint films, applicable to powder coated metal parts; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
