Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 45 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight | 58 kg | |
|---|---|---|
| Distributed tabletop load | 40 kg | |
| Concentrated impact point load | 15 kg | |
| Storage compartment load | 12 kg | |
| Caster rated capacity per set | 80 kg total | |
| Recommended user capacity | 4 people | |
| Swivel cycles | 10,000 cycles | |
| Surface heat resistance | 80 degrees C | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upper tabletop panel | Light grey stone-veined sintered-stone-look panel, 20 mm thick, with eased polished edge | |
|---|---|---|
| Storage drum shell | Matte warm-grey painted MDF or particleboard with curved laminated exterior | |
| Interior compartment | Dark brown wood-grain laminate or veneered board with vertical divider forming open bays | |
| Left support panel | Dark smoked-oak wood veneer or melamine panel with rounded front edge | |
| Bottom plinth | Black wood-grain or matte laminated circular base band, 50 mm high | |
| Internal rotating support | Powder-coated steel turntable bearing with concealed central pivot | |
| Caster hardware | Four 40 mm swivel casters with black twin wheels and zinc-plated brackets | |
| Panel board core | E1-class wood-composite panel at 18 mm nominal thickness | |
| Edge treatment | PVC or matching resin edge banding with 2 mm visible edge protection | |
| Fasteners and brackets | Carbon-steel screws, cam bolts, and corner brackets with zinc plating | |
| Foot contact surfaces | Black non-marking TPE or nylon caster treads | |
| Surface finish | Low-sheen matte paint on the drum and semi-polished stone-look top |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree rotating top | Upper oval panel rotates around a central bearing to expose or cover the circular storage drum | |
|---|---|---|
| Concealed open storage | Rotating the top reveals a divided wedge-shaped compartment for magazines, remotes, and blankets | |
| Mobile upper section | Two visible swivel casters under the support panel let the oval top roll during rotation and repositioning | |
| Fixed lower drum | The round cabinet rests on a full black plinth and remains stationary while the upper tabletop turns | |
| Nested space-saving position | The oval top can rotate over the drum to reduce the deployed footprint from 1200 mm to 900 mm | |
| Open-bay divided organization | At least one vertical divider separates the visible storage cavity into two accessible sections | |
| Floor-protecting mobility | Twin-wheel non-marking casters distribute load and reduce scratching on wood or tile floors | |
| Tool-free daily transformation | The top is moved by hand without removing objects from the fixed drum; heavy objects should be removed before rotation | |
| Stable asymmetric service mode | When extended, the top provides a 200 mm cantilevered display zone above the storage base | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Contemporary living room | Pairs with a three-seat sofa or sectional where the 420 mm height supports drinks and books | |
|---|---|---|
| Lounge and reception area | Provides a sculptural rotating table for casual guest seating in showrooms and offices | |
| Small apartment living space | Nested mode reduces the occupied footprint while retaining hidden storage for daily accessories | |
| Hotel suite or serviced apartment | Suitable as a decorative center table with concealed magazines and remote controls | |
| Model home staging | Neutral grey and dark oak finishes provide a high-contrast focal point with decorative trays and books | |
| Four-person casual seating | Best arranged between four lounge seats to share the oval serving surface from multiple sides | |
| Low-pile rug or hard-floor setting | Non-marking caster specification supports use on tile, wood, laminate, and rug-protected floors |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
