Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 600 x 450 x 760 mm | |
|---|---|---|
| Desk top thickness | 30 mm | |
| Desk height adjustment range | 760 mm | |
| Height adjustment increment | 30 mm | |
| Stool overall dimensions | 350 x 250 x 440 mm | |
| Stool seat thickness | 16 mm | |
| Stool height adjustment range | 440 mm | |
| Desk fixed leg tubing size | 30 x 60 x 1.5 mm | |
| Desk lift tube tubing size | 20 x 50 x 1.2 mm | |
| Cross brace tubing size | 20 x 40 x 1.2 mm | |
| Desk T-foot length | 450 mm | |
| Under-desk knee clearance height | 640 mm | |
| Under-desk apron depth | 80 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm |
Net weight / load capacity / users / durability
| Total set static load capacity | 200 kg | |
|---|---|---|
| Desktop impact resistance | 2.3 kg hammer strike without cracking | |
| Foot glide pull-off resistance | 1000 N | |
| Recommended user age range | 18 years | |
| Frame rust resistance coating durability | 500 hours salt spray without corrosion | |
| Edge impact resistance | 10000 repeated bump cycles without delamination | |
| Surface abrasion resistance | 2000 cycles without visible wear | |
| Warranty period | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop | Blue injection-molded ABS panel with rounded collision-safe edges | |
|---|---|---|
| Desk apron | Black powder-coated steel support frame under desktop | |
| Fixed desk legs | 1.5mm thick rectangular steel tube with black electrostatic powder coat | |
| Height adjustment lift tubes | 1.2mm thick steel tube with evenly spaced pin holes for locking | |
| Cross support brace | 1.2mm thick steel tube welded between desk legs for rigidity | |
| Stool seat | Blue molded ABS panel with rounded matching edges | |
| Stool frame | Black powder-coated steel tube with identical pin-hole height adjustment | |
| T-base foot glides | Injection-molded PP anti-slip caps with floor protection pads | |
| Height locking fasteners | M8 zinc-plated steel bolts and lock pins | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Desk height adjustment | 5 pin-locked positions with 30mm increments, secured by M8 locking bolts | |
|---|---|---|
| Structural stability | T-shaped floor feet and diagonal cross brace prevent wobble during writing use | |
| Collision protection | Rounded smooth edges on desk and seat eliminate sharp corner injury risks | |
| Floor protection | Non-marking PP glides prevent scratching on hard classroom floors | |
| Height reconfiguration | Tool-operated bolt locking prevents accidental height slippage during use | |
| Surface maintenance | Non-porous molded ABS surface resists ink stains and allows easy wipe cleaning | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| K-12 classroom use | Single-seat configuration suitable for standard 600mm per-student classroom spacing | |
|---|---|---|
| Home study space | Compact footprint fits small home study areas for children's daily homework use | |
| Tutoring center use | Durable easy-clean surface withstands high-traffic daily use in tutorial settings | |
| After-school program facilities | Collision-safe edges and stable base suit unsupervised student use environments | |
| Temporary training venue use | Lightweight frame allows easy repositioning for flexible room arrangements | |
| Bulk institutional procurement | Standardized sizing and construction aligns with public school furniture tender specifications | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1729-1:2015 | Applicable standard for functional and safety requirements for educational furniture | |
|---|---|---|
| EN 1729-2:2015 | Applicable standard for safety requirements and test methods for educational seating |
Standards applicable to China-market projects
| GB/T 3976-2014 | Applicable standard for functional size and safety of school desks and chairs | |
|---|---|---|
| GB 18584-2001 | Applicable standard for indoor decoration material limit of harmful substances | |
| GB/T 10357.1-1989 | Applicable standard for furniture mechanical performance test for tables |
This product must meet the following technical requirements: 1. GB/T 3976-2014: Applicable standard for functional size and safety of school desks and chairs; 2. GB 18584-2001: Applicable standard for indoor decoration material limit of harmful substances; 3. GB/T 10357.1-1989: Applicable standard for furniture mechanical performance test for tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
