Automatic mm / inch conversion · Core engineering specifications
| Overall table dimensions | 1400 x 750 x 480 mm | |
|---|---|---|
| Tabletop thickness | 30 mm | |
| Leg cross-section size | 80 x 80 mm | |
| Lower shelf height from floor | 120 mm | |
| Undershelf vertical clearance | 270 mm | |
| Drawer internal usable depth | 120 mm | |
| Drawer front panel dimensions | 300 x 180 mm | |
| Table edge overhang past legs | 50 mm | |
| Floor to tabletop underside clearance | 390 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Maximum distributed tabletop static load | 220 kg | |
|---|---|---|
| Maximum lower shelf static load | 80 kg | |
| Maximum single drawer static load | 15 kg | |
| Net product weight | 38 kg | |
| Surface finish abrasion resistance | 2000 cycles | |
| Wood panel moisture content | 12% | |
| Seated user capacity around table | 4 people | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop panel | Solid rubberwood substrate with walnut stain, open-pore matte lacquer finish | |
|---|---|---|
| Four support legs | Solid square wood, finished to match tabletop with rounded bottom edges | |
| Lower open shelf | 18mm thick solid wood slat/panel, routed edge, matching walnut finish | |
| Drawer body | Solid wood drawer box with dovetail or dowel joinery, sanded interior | |
| Drawer slides | Cold-rolled steel side-mounted 3-section slides, zinc-plated finish | |
| Drawer pull/handle | Recessed integrated wood pull, flush with drawer front, no protruding hardware | |
| Foot pads | 6mm thick non-marking PE anti-slip pads fixed to leg bottoms | |
| Surface coating | Low-VOC matte nitrocellulose lacquer, stain-resistant, scratch-resistant top coat | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Side storage drawer | Single side-mounted drawer on left end, slides fully outward 300mm for small item storage | |
|---|---|---|
| Open lower storage shelf | Full-width open fixed shelf below tabletop for books, baskets and display items | |
| Leveling stability | Fixed solid wood legs with non-slip pads, suitable for flat hard or carpeted floors | |
| Load distribution | Thick legs positioned at corners to evenly distribute static loads without mid-span sag | |
| Edge protection | Smooth rounded edge profile on all tabletop perimeter to reduce impact injury | |
| Surface maintenance | Non-porous lacquered surface cleanable with damp soft cloth, no special treatment required | |
| Assembly option availability | Knock-down assembly with pre-drilled leg and shelf connectors, on-site installation possible | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room placement | Positioned in front of L-shaped or 4seat sofas for drinks, decor and remote storage | |
|---|---|---|
| New Chinese style interior matching | Coordinates with walnut wood frame sofas, marble tile or wood flooring and neutral fabric soft furnishings | |
| Family daily use scenario | Supports everyday placement of books, teaware, vases and media controls for casual use | |
| Small apartment living space suitability | Open shelf and drawer storage eliminates need for separate side storage units in compact rooms | |
| Tea room casual seating area use | Suitable for low tea service set placement adjacent to casual floor or sofa seating | |
| Commercial lounge space application | Usable in hotel lobby lounge areas or VIP reception rooms with matching wood seating sets |
EU Market Access Requirements* EN Standards
| EN 12521:2015 Furniture - Strength, durability and safety for domestic tables | Applicable for static load, impact and stability performance acceptance | |
|---|---|---|
| EN 71-3:2019+A1:2021 Safety of toys - Migration of certain elements | Referenced for surface coating heavy metal limits if used in family spaces |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for dimensional tolerance, surface quality and structural strength acceptance | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde emission limit verification for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for dimensional tolerance, surface quality and structural strength acceptance; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for formaldehyde emission limit verification for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
