Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 1600 x 1500 x 1250 mm | |
|---|---|---|
| Minimum desktop height | 720 mm | |
| Maximum desktop height | 1250 mm | |
| Lift travel stroke | 530 mm | |
| Main desktop thickness | 25 mm | |
| Main desktop depth | 700 mm | |
| Storage return cabinet height | 750 mm | |
| Storage return cabinet depth | 500 mm | |
| Seated knee clearance width | 800 mm | |
| Seated knee clearance minimum height | 670 mm | |
| Edge banding thickness | 2 mm | |
| T-base lift leg foot length | 600 mm | |
| Cable grommet diameter | 60 mm | |
| Adjustable open shelf height | 320 mm | |
| Leveler foot adjustment range | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Net weight range | 100 kg | |
| Lift operating speed | 35 mm/s | |
| Lift mechanism cycle rating | 10000 cycles | |
| Recommended user weight capacity | 136 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Operating noise level | 48 dB | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | Light oak woodgrain laminate over P2 grade MDF core | |
|---|---|---|
| Storage cabinet panels | White matte laminate over particleboard core | |
| Height-adjustable leg | 1.5 mm wall thickness powder-coated white steel | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Lock hardware | Zinc alloy keyed cam lock for top drawer | |
| Leveler feet | Nylon base with steel threaded stem |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment control | LED digital control panel with 3 programmable memory presets | |
|---|---|---|
| Anti-collision protection | Sensors detect obstructions during lift and reverse direction | |
| Lockable storage drawer | Keyed lock secures upper drawer for confidential document storage | |
| Cable management | 60 mm desktop grommet routes cables from work surface to under desk |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workspace | Fits compact corner spaces to provide sit-stand work surface and storage | |
|---|---|---|
| Open plan office workstation | Suitable for individual work zones with integrated storage to reduce clutter |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office work desk dimensional and stability requirements | |
|---|---|---|
| EN 527-2:2016 | Applies to desk mechanical safety and structural performance requirements | |
| EN 14073-2:2004 | Applies to office storage cabinet safety and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products for strength, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applies to office storage units performance and safety requirements |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to desk dimensional, strength and durability requirements for office furniture | |
|---|---|---|
| GB/T 3327-2016 | Applies to storage cabinet structural and performance requirements | |
| GB 18580-2017 | Applies to formaldehyde emission limits for engineered wood panels |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to desk dimensional, strength and durability requirements for office furniture; 2. GB/T 3327-2016: Applies to storage cabinet structural and performance requirements; 3. GB 18580-2017: Applies to formaldehyde emission limits for engineered wood panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
