| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Primary Component Thickness | 40 mm according to load-bearing role | |
|---|---|---|
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Maximum static load capacity | 80 kg | |
|---|---|---|
| Lifting speed at rated load | 38 mm/s | |
| Operating noise level during height adjustment | 45 dB | |
| Net product weight | 23 kg | |
| Adjustable leveler height adjustment range | 10 mm | |
| Recommended maximum user weight plus equipment | 80 kg | |
| Lift cycle rating for frame mechanism | 10000 cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | 25 mm thick E1-grade particleboard with light oak melamine laminate | |
|---|---|---|
| Desktop edge banding | 1 mm thick PVC edge trim matching light oak finish | |
| Lifting frame and columns | 1.5 mm thick cold-rolled steel with matte white polyester powder coating | |
| T-leg outrigger feet | Rectangular steel tube welded to column base with matching white powder coat | |
| Leveler feet | Black rubber-padded nylon adjustable glides with threaded steel stem | |
| Control keypad housing | Black ABS plastic with membrane button panel and digital height display |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment control | Digital LED keypad with 3 programmable height memory presets | |
|---|---|---|
| Safety anti-collision function | Gyroscope sensor detects obstruction, stops and reverses lift 50 mm | |
| Leveling adjustment | Threaded glide feet rotate to adjust height by 10 mm for uneven floors | |
| Power supply rating | 29V DC low-voltage adapter with regional standard plug |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workstation | Fits compact 1200 mm wide spaces for single-user computer and document work | |
|---|---|---|
| Small corporate hot-desking station | Sit-stand adjustability supports alternating seated and standing work postures |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office worktable safety, dimensional and strength performance requirements | |
|---|---|---|
| EN 527-2:2016 | Applies to adjustable-height office desk specific mechanical safety requirements | |
| EN 1335-1:2020 | Referenced for ergonomic desk height range alignment with office chair seating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products static load, durability and stability testing for office use |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office desk dimensional, structural and stability testing requirements | |
|---|---|---|
| GB/T 10357.1-2013 | Applies to desk mechanical performance test methods for strength and durability | |
| GB 18580-2017 | Applies to formaldehyde emission limits for engineered wood desktop substrate |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office desk dimensional, structural and stability testing requirements; 2. GB/T 10357.1-2013: Applies to desk mechanical performance test methods for strength and durability; 3. GB 18580-2017: Applies to formaldehyde emission limits for engineered wood desktop substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
