Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1400 x 600 x 1220 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Minimum desktop height | 730 mm | |
| Maximum desktop height | 1220 mm | |
| Under-desk seated knee clearance | 680 mm | |
| Leg column cross-section | 80 x 50 mm | |
| Foot base length | 550 mm | |
| Foot base width | 80 mm | |
| Leveling glide diameter | 20 mm | |
| Control panel length | 120 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Maximum static load capacity | 80 kg | |
|---|---|---|
| Net product weight | 31 kg | |
| Lift speed | 20 mm/s | |
| Operating noise level | 50 dB | |
| Motor lift cycle rating | 20000 cycles | |
| Supported user weight | 120 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | 25mm melamine-faced E1 grade particleboard | |
|---|---|---|
| Lift frame and legs | 1.5mm thick powder-coated cold-rolled steel | |
| Leveling glides | Nylon base with rubber contact pad | |
| Internal lift motor assembly | DC 29V electric drive motor | |
| Control panel housing | ABS plastic with membrane button interface | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | Electric push-button control with 3 programmable memory presets | |
|---|---|---|
| Floor leveling | 10mm adjustable height on each foot glide for uneven surfaces | |
| Safety protection | Anti-collision auto-rebound and overload shutdown | |
| Height display | Digital LED readout of current desktop height on control panel |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workstation | Fits single monitor and laptop setup for remote work sit-stand use | |
|---|---|---|
| Small open office workstation | Minimalist white finish suits modern open plan office layouts |
EU Market Access Requirements* EN Standards
| Office furniture strength and stability | EN 527:2002 | |
|---|---|---|
| Electrical equipment safety | EN 60335:2012 |
US and Canada office-furniture standards
| Height adjustable desk durability | ANSI/BIFMA X2021 | |
|---|---|---|
| Lift mechanism cycle testing | ANSI/BIFMA X2021Section 11 |
Standards applicable to China-market projects
| Desktop formaldehyde emission | GB/T 39600E1 grade | |
|---|---|---|
| Desk structural stability | GB/T 3326 |
This product must meet the following technical requirements: 1. Desktop formaldehyde emission: GB/T 39600E1 grade; 2. Desk structural stability: GB/T 3326; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
