Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1800 x 750 x 1250 mm | |
|---|---|---|
| Minimum desktop height | 600 mm | |
| Height adjustment travel | 650 mm | |
| Desktop thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| T-foot length per leg | 600 mm | |
| Leg column outer dimension | 70 x 70 mm | |
| Control panel size | 120 x 60 mm | |
| Seated knee clearance width | 1600 mm | |
| Rounded corner radius | 30 mm | |
| Scallop cutout depth | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Maximum static load capacity | 140 kg | |
|---|---|---|
| Lift speed | 40 mm/s | |
| Operating noise level | 50 dB | |
| Net product weight | 65 kg | |
| Warranty period | 10 years | |
| Anti-collision reaction sensitivity | 10 N | |
| Adjustable height memory presets | 4 positions | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | 25mm MDF core with white melamine laminate | |
|---|---|---|
| Desktop edge trim | 2mm black PVC edge banding | |
| Lift frame and legs | 1.8mm thick cold-rolled steel with rose gold powder coat | |
| Stability feet | Steel T-feet with non-slip rubber leveling glides | |
| Control panel housing | ABS plastic with soft-touch button interface | |
| Internal lift components | Steel gear drive with reinforced motor mounts |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment mechanism | Dual motor electric lift with 3-stage telescoping legs | |
|---|---|---|
| Control interface | Under-desk mounted digital keypad with height display and memory presets | |
| Safety feature | Integrated anti-collision detection to stop and reverse on obstruction | |
| Cable management | Integrated under-desk cable routing tray to organize power and data cords |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping cartons | 2 | |
|---|---|---|
| Shipping carton dimensions (desktop) | 1850 x 800 x 80 mm | |
| Shipping carton dimensions (frame kit) | 850 x 300 x 200 mm | |
| Total packaged gross weight | 70 kg | |
| Total shipment volume | 0.17 CBM | |
| Assembly time | 15 minutes |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workstations | Ergonomic sit-stand function supports long work sessions with reduced sedentary strain | |
|---|---|---|
| Open plan office desks | Compact T-leg design minimizes footprint while supporting multi-monitor setups |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office worktables safety, strength and dimensional requirements | |
|---|---|---|
| EN 15372:2016 | Applies to strength, durability and stability requirements for office tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products static, dynamic and cyclic load performance testing |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to desk dimensional, strength and stability requirements for office furniture | |
|---|---|---|
| GB/T 4897.3-2017 | Applies to particleboard substrate quality for furniture desktop use |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to desk dimensional, strength and stability requirements for office furniture; 2. GB/T 4897.3-2017: Applies to particleboard substrate quality for furniture desktop use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
