Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation dimensions | 1800 x 1650 x 1270 mm | |
|---|---|---|
| Per-user work surface dimensions | 1800 x 800 mm | |
| Desktop thickness | 25 mm | |
| Minimum desktop height (seated position) | 620 mm | |
| Maximum desktop height (standing position) | 1270 mm | |
| Height adjustment stroke | 650 mm | |
| Central fabric privacy screen height | 900 mm | |
| Central fabric privacy screen thickness | 30 mm | |
| Steel lift leg column cross-section | 90 x 60 mm | |
| Under-desk seated knee clearance width per user | 1600 mm | |
| Under-desk minimum seated knee clearance height | 595 mm | |
| Vertical segmented cable spine length (fully extended) | 1288 mm | |
| Cable spine segment cross-section width | 129 mm | |
| Steel cross-brace height from floor | 320 mm | |
| Adjustable foot glide diameter | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static lifting capacity per work surface | 120 kg | |
|---|---|---|
| Total product net weight | 87 kg | |
| Height adjustment speed | 38 mm/s | |
| Operating noise level during height adjustment | 50 dB | |
| Recommended user capacity | 2 people | |
| Cable spine cable capacity per channel | 8 power/data cables | |
| Frame static load rating (without desktop) | 150 kg | |
| Standard commercial warranty period | 10 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop | 25mm E0-grade melamine-faced particleboard with impact-resistant PVC edge banding, white matte finish | |
|---|---|---|
| Lift frame and legs | 3 mm thick powder-coated cold-rolled steel, white matte finish, square telescoping columns | |
| Central privacy divider | Fabric-upholstered fibreboard core, brown woven fabric surface, pinnable acoustic surface | |
| Cable management spines | Segmented polypropylene plastic with weighted steel base plates, grey matte finish | |
| Adjustment control panel | ABS plastic housing with membrane button interface and LED digital display | |
| Foot glides | Injection-moulded nylon with non-slip rubber base pads, adjustable height for floor levelling |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment mechanism | Dual independent electric motors per work surface, smooth telescoping leg actuation for independent sit-stand adjustment | |
|---|---|---|
| Control interface functions | 4 programmable height memory presets, LED height display, keypad lock, sit-stand posture reminder, USB charging port | |
| Safety feature | Integrated anti-collision/anti-tilt sensor that stops and reverses movement if obstruction is detected | |
| Cable management system | Two articulated segmented cable spines per user, under-desk cable trays, desktop cable cutouts to contain wiring during height adjustment |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office work zones | Suitable for 2-person clustered workstations in open offices, providing visual privacy with central divider | |
|---|---|---|
| Activity-based working environments | Supports sit-stand working transitions for employee ergonomic comfort and reduced sedentary time |
EU Market Access Requirements* EN Standards
| Office furniture safety and strength requirements | EN 527:2002+A1:2019 | |
|---|---|---|
| Office furniture stability testing | EN 1730:2000 | |
| Formaldehyde emission from wood panels | EN 312:2010 |
US and Canada office-furniture standards
| Height-adjustable desk performance standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Electrical furniture safety requirement | ANSI/BIFMA e2019e |
Standards applicable to China-market projects
| Desktop panel formaldehyde emission | GB/T 17657 | |
|---|---|---|
| Office desk structural strength and stability | GB/T 3326 | |
| Electrical safety for height adjustment system | GB 4706.1 |
This product must meet the following technical requirements: 1. Desktop panel formaldehyde emission: GB/T 17657; 2. Office desk structural strength and stability: GB/T 3326; 3. Electrical safety for height adjustment system: GB 4706.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
