Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall desk dimensions | 1400 x 1640 x 1315 mm | |
|---|---|---|
| minimum desktop height | 665 mm | |
| per-station work surface size | 1400 x 800 mm | |
| desktop thickness | 25 mm | |
| central privacy divider height | 800 mm | |
| privacy divider thickness | 22 mm | |
| telescopic lift column diameter | 80 mm | |
| cross-brace section size | 40 x 20 mm | |
| minimum seated knee clearance height | 640 mm | |
| leveling glide height adjustment range | 10 mm | |
| articulated cable chain length at maximum height | 1100 mm | |
| control panel size | 150 x 40 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| total static desktop load capacity | 120 kg | |
|---|---|---|
| height adjustment speed | 38 mm/s | |
| lift motor cycle rating | 20000 cycles | |
| adjustment operating noise level | 55 dB | |
| product net weight | 114 kg | |
| structural frame warranty | 10 years | |
| electrical component warranty | 5 years | |
| surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| worktop surface | 25mm thick MFC board with light oak melamine laminate, 2mm PVC edge banding | |
|---|---|---|
| lift frame and legs | 1.5mm thick cold-rolled steel with matte white powder-coated finish | |
| central privacy divider cover | Tackable polyester fabric in warm brown finish | |
| privacy divider core | Rigid PVC panel with 10mm acoustic foam padding | |
| cable management chains | Flexible segmented polypropylene articulated cable spines | |
| leveling glides | Nylon base with steel threaded adjustment stem |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| height adjustment mechanism | Dual-motor electric lift system with 4 programmable memory presets, operated via under-desk control panel | |
|---|---|---|
| safety feature | Anti-trap collision stop that halts adjustment upon contact with obstructions | |
| cable management system | Two articulated segmented cable chains route power and data cables from desktop to floor, preventing pinching during height changes | |
| installation and leveling | Adjustable threaded glides on all four leg bases compensate for uneven floors, horizontal steel cross-bracing prevents frame wobble |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| open plan office workspaces | Supports two adjacent users with central divider for visual privacy and distraction reduction | |
|---|---|---|
| agile office sit-stand environments | Allows users to switch between seated and standing working positions to reduce sedentary time |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Specifies safety, strength and stability requirements for office work tables and desks | |
|---|---|---|
| EN 527-2:2016 | Specifies dimensional requirements for office workstations including sit-stand desks | |
| EN 1335-2:2009 | Reference for office seating interface compatibility with adjustable desk height ranges |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for safety, durability and structural performance of desk products | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Standard for power-adjustable height-adjustable desk systems and mechanisms |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office desk dimensional, strength and durability requirements for general office furniture | |
|---|---|---|
| GB/T 24821-2009 | Applies to safety and performance requirements for electric height-adjustable office tables | |
| GB 18584-2001 | Applies to formaldehyde emission limits for wood-based furniture panels used in indoor office spaces |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office desk dimensional, strength and durability requirements for general office furniture; 2. GB/T 24821-2009: Applies to safety and performance requirements for electric height-adjustable office tables; 3. GB 18584-2001: Applies to formaldehyde emission limits for wood-based furniture panels used in indoor office spaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
