Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1400 x 700 x 1280 mm | |
|---|---|---|
| Minimum desktop height | 600 mm | |
| Maximum desktop height | 1280 mm | |
| Lifting travel stroke | 680 mm | |
| Tabletop thickness | 25 mm | |
| Lifting column outer cross-section | 80 x 50 mm | |
| T-shaped foot length | 600 mm | |
| T-shaped foot width | 70 mm | |
| Seated knee clearance width | 1000 mm | |
| Seated minimum knee clearance height | 580 mm | |
| Standing elbow clearance at max height | 1260 mm | |
| Control keypad width | 120 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Maximum vertical static load capacity | 140 kg | |
|---|---|---|
| Lifting speed | 38 mm/s | |
| Operating noise level | 55 dB | |
| Duty cycle | 5 minutes on / 18 minutes off | |
| Net product weight | 45 kg | |
| Frame static load cycle rating | 10000 cycles | |
| Power input rating | 240V AC universal voltage | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | 25mm thick particleboard core with white matte laminate surface | |
|---|---|---|
| Lifting columns | 1.5mm thick powder-coated carbon steel, 3-stage telescoping | |
| Support feet | 2mm thick powder-coated carbon steel T-shaped design with rounded ends | |
| Cross support brackets | 1.2mm thick powder-coated steel connecting columns to tabletop | |
| Control keypad housing | ABS plastic with membrane push buttons | |
| Internal drive components | Steel lead screws with nylon gear drives |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment mechanism | Dual electric motor drive, one motor per lifting column for balanced lifting | |
|---|---|---|
| Control function | 4 programmable memory height presets with digital height display | |
| Safety feature | Anti-collision sensitivity system that stops and reverses when hitting obstacles | |
| Stability feature | Integrated adjustable leveling glides on each foot to correct uneven floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workstation | Supports sit-stand work patterns for remote workers using monitors and peripherals | |
|---|---|---|
| Open plan office individual workstation | Fits standard cubicle and open office layouts for employee daily use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office worktables dimensional, safety and strength requirements for EU procurement | |
|---|---|---|
| EN 527-2:2016 | Applies to height-adjustable office desk mechanical safety and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products static, dynamic and durability test requirements for North American procurement |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office desk dimensional, stability and strength requirements for domestic Chinese procurement | |
|---|---|---|
| GB/T 3327-2016 | Applies to furniture mechanical surface durability and material performance requirements |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office desk dimensional, stability and strength requirements for domestic Chinese procurement; 2. GB/T 3327-2016: Applies to furniture mechanical surface durability and material performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
