Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1800 x 1600 x 1250 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static desktop load capacity | 100 kg | |
|---|---|---|
| Net product weight | 95 kg | |
| Lift speed | 38 mm/s | |
| Duty cycle | 10% | |
| Noise level during lifting | 50 dB | |
| Adjustable leveling range | 10 mm | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm E1 grade particleboard with walnut wood grain melamine laminate, PVC edge banding | |
|---|---|---|
| Lifting column | 2mm thick powder-coated matte dark grey steel, 3-stage telescopic structure | |
| Storage cabinet panels | 18mm E1 grade particleboard with two-tone walnut and light grey melamine finish | |
| Drawer lock | Zinc alloy keyed cam lock with brushed chrome faceplate | |
| Cable grommet | ABS plastic round desk cable port with brushed silver finish | |
| Leveling glides | Glass-filled nylon adjustable feet with non-slip rubber base |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | Electric motorized lift with digital memory keypad, 4 preset height positions | |
|---|---|---|
| Storage configuration | Side cabinet includes 2 closed doors, 1 open 2-tier shelf, 1 lockable drawer, 1 lower cabinet door | |
| Cable management | Round cable grommet routes wires from desk surface to internal cabinet space | |
| Leveling adjustment | Rotating glides stabilize the unit on uneven floor surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Applicable space | Private executive offices, open office workstations, home office studies | |
|---|---|---|
| Target user | Office workers, remote professionals, managerial staff |
EU Market Access Requirements* EN Standards
| EN 527-2:2016 | Applies to safety, strength and durability requirements for office work tables | |
|---|---|---|
| EN 1335-2:2000 | Applies to general office furniture stability requirements for desk units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to performance and durability testing standard for desk products |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office desk dimensional, strength and durability requirements for general workstations | |
|---|---|---|
| GB 18580-2017 | Applies to formaldehyde emission limits for wood-based panel components used in indoor furniture |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office desk dimensional, strength and durability requirements for general workstations; 2. GB 18580-2017: Applies to formaldehyde emission limits for wood-based panel components used in indoor furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
