Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total weight capacity for desk top | 80 kg | |
|---|---|---|
| Static load capacity for cabinet top | 50 kg | |
| Net weight of complete desk unit | 85 kg | |
| Recommended maximum user weight for seated use | 120 kg | |
| Lift mechanism cycle life | 10000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desk top and cabinet panels | 25mm E1 grade engineered particleboard with light oak melamine laminate finish | |
|---|---|---|
| Cabinet front door panel | 18mm engineered MDF with matte white powder-coated paint finish | |
| Lift leg column and T-base | 2mm thick cold-rolled steel with matte white powder-coated finish | |
| Cabinet leveler glides | Injection-molded nylon with non-slip rubber base pads | |
| Cable grommet trim | Brushed ABS plastic with recessed cable opening | |
| Hardware and slide rails | Cold-rolled steel drawer slides with zinc plating |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment function | Electric single-motor drive adjusts work surface from sitting to standing height with 480mm total travel | |
|---|---|---|
| Integrated cable management | Oval top grommet routes cables from work surface down into cabinet interior for concealed wiring | |
| Storage cabinet function | Enclosed ventilated cabinet with adjustable internal shelves for CPU, documents and office supplies | |
| Leveling adjustment | Rotating nylon glides on cabinet base and lift leg foot adjust to compensate for uneven floor surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive office | Provides L-shaped work surface with height adjustment and adjacent storage for managers and senior staff | |
|---|---|---|
| Home office workspace | Compact L-configuration fits residential home offices with sit-stand functionality and concealed storage |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
