Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W×D×H) | 1400 x 700 x 1250 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Minimum desktop height (seated position) | 600 mm | |
| Vertical lift travel distance | 650 mm | |
| T-shaped stabilizing foot length | 600 mm | |
| T-foot width | 70 mm | |
| Leg column cross-section size | 70 x 70 mm | |
| Under-desk seated knee clearance height | 600 mm | |
| Under-desk knee clearance width | 1260 mm | |
| Leveling foot adjustment range | 10 mm | |
| Control keypad dimensions (W×H) | 150 x 30 mm | |
| Edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Maximum static desktop load capacity | 140 kg | |
|---|---|---|
| Vertical lift speed | 40 mm/s | |
| Operating noise level during height adjustment | 50 dB | |
| Lift cycle durability rating | 100000 cycles | |
| Net product weight | 68 kg | |
| Anti-collision force detection threshold | 15 N | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate and finish | 25mm particleboard core with matte black melamine laminate, scratch-resistant surface | |
|---|---|---|
| Lift leg and frame structure | 1.5mm thick carbon steel with grey powder-coated finish, 3-stage telescoping columns | |
| T-shaped stabilizing feet | 2mm thick welded carbon steel with matching powder-coated finish, rounded end caps | |
| Leveling glides | Injection-molded nylon base with threaded steel stem, non-marking rubber contact pad | |
| Control keypad housing | Matte black ABS plastic housing with membrane button panel | |
| Cable management components (standard) | 1mm thick powder-coated steel cable tray with plastic cable ties |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment mechanism | Dual-motor electric lift with 3-stage telescoping legs, synchronous drive for level movement | |
|---|---|---|
| Memory preset controls | 4 programmable height presets with up/down adjustment buttons and digital height readout | |
| Anti-collision safety feature | Integrated obstruction detection that stops and reverses lift movement when contact is detected | |
| Floor stability adjustment | Threaded nylon leveling feet at each foot end to compensate for uneven floor surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workstation | Fits single-user home workspaces for alternating sitting and standing work | |
|---|---|---|
| Open-plan corporate office | Meets commercial office durability and ergonomic requirements for daily employee use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | European standard for office worktables: dimensional and safety requirements | |
|---|---|---|
| EN 527-2:2016 | Specifies mechanical safety, strength and durability test methods for office desks | |
| EN 12521:2015 | Covers stability and load requirements for free-standing domestic and office tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Updated standard for height-adjustable desk safety and durability requirements | |
|---|---|---|
| BIFMA G1-2013 | Ergonomic guidelines for adjustable workstation height and clearance dimensions |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to desk dimensional, structural and stability requirements for office furniture | |
|---|---|---|
| GB/T 3327-2016 | Covers mechanical performance test methods for office desk strength and durability | |
| GB 18584-2001 | Specifies formaldehyde emission limits for wood-based furniture panels |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to desk dimensional, structural and stability requirements for office furniture; 2. GB/T 3327-2016: Covers mechanical performance test methods for office desk strength and durability; 3. GB 18584-2001: Specifies formaldehyde emission limits for wood-based furniture panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
