Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint (max height) | 1600 x 800 x 1290 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Minimum desktop height | 630 mm | |
| Maximum desktop height | 1290 mm | |
| Seated knee clearance height | 605 mm | |
| Seated knee clearance width | 1420 mm | |
| T-base foot length | 700 mm | |
| Leveling glide diameter | 60 mm | |
| Control keypad width | 120 mm | |
| Leg column cross-section | 80 x 50 mm | |
| Desktop corner radius | 30 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Maximum static desktop load | 120 kg | |
|---|---|---|
| Lift speed | 35 mm/s | |
| Operating noise level | 50 dB | |
| Lift mechanism cycle life | 20000 cycles | |
| Frame and motor warranty | 10 years | |
| Electronics and desktop warranty | 2 years | |
| Recommended user weight capacity | 120 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate and finish | E1-grade particleboard core, light oak melamine laminate, stain-resistant surface | |
|---|---|---|
| Lift frame and columns | 1.5 mm thick cold-rolled steel, white matte powder-coated finish | |
| T-base stabilizing feet | 1.8 mm thick steel tube, matching white powder coat, welded to column bases | |
| Leveling glides | Reinforced thermoplastic stem, non-marking rubber base, 10 mm adjustment range | |
| Height control keypad | ABS plastic housing, backlit LED digital display, membrane buttons | |
| Internal drive components | Steel lead screws, NEMA-grade electric motors, overheat protection circuitry |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment operation | Electric dual-motor drive, smooth vertical travel between seated and standing positions | |
|---|---|---|
| Memory preset function | 4 programmable height presets for one-touch position recall | |
| Collision safety feature | Anti-collision sensor stops and reverses 50 mm on obstruction contact | |
| Level adjustment function | Threaded glides adjust 10 mm to compensate for uneven floor surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workspace | Suitable for individual remote work, supporting both seated and standing work postures | |
|---|---|---|
| Commercial open office | Suitable for hot-desking and assigned workstations in professional office environments |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable European standard for office worktable safety, strength and stability | |
|---|---|---|
| EN 527-2:2016 | Applicable standard for height-adjustable office desk mechanical performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable standard for desk products: static, dynamic and durability performance testing |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applicable for desk dimension, stability and strength testing for office furniture | |
|---|---|---|
| GB/T 35607-2017 | Applicable for low-VOC emission requirements for wood-based desktop materials |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applicable for desk dimension, stability and strength testing for office furniture; 2. GB/T 35607-2017: Applicable for low-VOC emission requirements for wood-based desktop materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
