Reddish Brown Double-Pedestal Executive Office Desk (model OFD-DP1400-3DR1DC) is listed under Traditional CEO Desk, with overall dimensions of 1400 × 700 × 760 mm and main material of MDF. Load capacity: 100 kg. Certifications: Traditional,style,fixed,double,pedestal,lockable,storage,cable,grommet. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1400 x 700 x 760 mm | |
|---|---|---|
| Worksurface thickness | 25 mm | |
| Cabinet panel thickness | 25 mm | |
| PVC edge band thickness | 2 mm | |
| Left pedestal dimensions | 450 x 520 x 680 mm | |
| Right cabinet pedestal dimensions | 450 x 520 x 680 mm | |
| Central knee opening width | 500 mm | |
| Knee clearance height | 620 mm | |
| Drawer internal height (per drawer) | 180 mm | |
| Right cabinet internal height | 600 mm | |
| Cable grommet diameter | 60 mm | |
| Bullnose edge overhang | 30 mm | |
| Plinth base height | 60 mm | |
| Hardware pull length | 120 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Worksurface static load capacity | 100 kg | |
|---|---|---|
| Product net weight | 75 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Drawer lock cycle rating | 10000 cycles | |
| Recommended user weight capacity | 136 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worksurface core | E1 grade high density fiberboard | |
|---|---|---|
| Worksurface finish | Reddish brown woodgrain thermally fused laminate | |
| Edge treatment | 2mm thick PVC bullnose edge banding | |
| Cabinet panels | 18mm thick melamine-faced particleboard | |
| Hardware components | Zinc alloy silver finished bar pulls, copper-core key lock, cold-rolled steel slides | |
| Cable grommet | ABS plastic round wire management grommet |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Left 3 vertically stacked lockable drawers, right single door enclosed cabinet | |
|---|---|---|
| Cable management | Single 60mm diameter rear desk grommet for monitor and peripheral wiring | |
| Drawer operation | 3-section full extension ball bearing slides for full access to drawer contents | |
| Locking system | Keyed lock secures all three left drawers for private document storage |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Applicable space | Private staff offices, executive workstations, administrative work areas | |
|---|---|---|
| Target user | Office staff, administrative personnel, junior managers |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for general office desk use | |
|---|---|---|
| EN 527-2:2016 | Office work tables, dimensional and functional requirements for seated workstations |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for static load, durability and stability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural stability and dimensional tolerances | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade required for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural stability and dimensional tolerances; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade required for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
