Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall L-shaped footprint | 3200 x 2000 x 760 mm | |
|---|---|---|
| Main work surface | 3200 x 1100 mm | |
| Return work surface | 1800 x 900 mm | |
| Work-surface thickness | 50 mm | |
| Visible top edge thickness | 60 mm | |
| Black writing pad | 2200 x 450 x 4 mm | |
| Central knee-well width | 900 mm | |
| Knee-well height under apron | 620 mm | |
| Minimum seated knee depth | 700 mm | |
| Left pedestal | 900 x 1050 x 680 mm | |
| Right pedestal and return base | 900 x 1800 x 680 mm | |
| Front modesty panel | 2200 x 450 x 25 mm | |
| Toe-kick recess height | 80 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static distributed top load | 120 kg | |
|---|---|---|
| Concentrated monitor-zone load | 45 kg | |
| Return work-surface load | 60 kg | |
| Drawer slide load per drawer | 35 kg | |
| File drawer load | 45 kg | |
| Drawer slide durability | 50,000 cycles | |
| Hinge durability for cabinet doors | 100,000 cycles | |
| Recommended user weight at workstation | 150 kg | |
| Net weight range | 280 kg | |
| Static distributed desktop load | 120 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top substrate | HDF or MDF engineered-wood core, 50 mm thick, with solid-wood edge trim | |
|---|---|---|
| Top facing | Red-brown select wood veneer with high-gloss clear painted finish | |
| Side and front panels | Wood-veneer engineered panels with framed traditional panel molding | |
| Writing surface | Black smooth leather-look or vinyl desk pad inset across central work area | |
| Internal cabinet material | Engineered-wood cabinet boards with matching veneer or sealed interior finish | |
| Drawer slides | Side-mounted steel ball-bearing full-extension slides | |
| Handles and locks | Metal pull handles with keyed pedestal locking cylinders | |
| Base and plinth | Wood-veneer built-up plinth with recessed toe kick and leveling glides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
|---|---|---|
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Suits director, president or owner offices where L-shaped computer work, signing and visitor discussion occur in one workstation. | |
|---|---|---|
| Management meeting support | The return provides a side surface for documents, printer placement or short side-by-side discussions without using a separate meeting table. |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
