Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed desktop static load | 120 kg | |
|---|---|---|
| Return-surface static load | 60 kg | |
| Drawer or pedestal static load | 30 kg per drawer | |
| Door shelf static load | 25 kg per shelf | |
| Seating capacity | 1 executive user plus 2 visitor chairs | |
| Product net weight | 180 kg | |
| Hardware cycle target | 50,000 drawer and door operations | |
| Recommended floor protection rating | Four 60 mm-wide floor contact zones | |
| Warranty duration for procurement comparison | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate and veneer | Engineered-wood core with reddish-brown wood veneer and molded edge banding | |
|---|---|---|
| Support cabinets and modesty panels | Wood-based panel cases finished in matching veneer with framed recessed panels | |
| Dark work or cable inset | Dark green leather-look or laminated writing panel set into the desktop | |
| Front privacy panel | Dark green inset panel in a wood-framed modesty section | |
| Hardware | Metal drawer pulls and hinges with a brass or bronze-tone finish | |
| Edge and base trim | Raised wood-look rails, corner posts, and stepped plinth molding |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| L-shaped work layout | Main 2400 mm desk and left 1200 mm return create separate primary-work and secondary-equipment zones | |
|---|---|---|
| Integrated storage | Left return cabinet provides enclosed storage with a visible side handle, suitable for CPU, files, or personal storage | |
| Fixed installation and privacy design | Floor-standing plinth bases support the desk while the front modesty panel conceals the user's leg area | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office application | Suitable for a private manager office where the 2400 mm main surface and return support computer work, documents, signing, and visitor discussions | |
|---|---|---|
| Matching filing area | Pairs with the shown full-height bookcase for binders, display objects, and concealed storage in a traditional wood-finish office |
EU Market Access Requirements* EN Standards
| Office desk safety recommendation | EN 527safety, strength, and durability requirements for office tables | |
|---|---|---|
| Office desk mechanical test recommendation | EN 527structural and dimensional test methods | |
| Office furniture storage safety | EN 14073safety requirements for office storage furniture | |
| Formaldehyde panel classification | EN 13986 wood-based panels for construction and furniture use |
Standards applicable to China-market projects
| Wood furniture panel acceptance | GB/T 3324 general technical requirements for wooden furniture | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18580 emission limits for indoor wood-based panels | |
| Furniture hardware acceptance | GB/T 3325 general technical requirements for metal furniture hardware |
This product must meet the following technical requirements: 1. Wood furniture panel acceptance: GB/T 3324 general technical requirements for wooden furniture; 2. Formaldehyde emission recommendation: GB 18580 emission limits for indoor wood-based panels; 3. Furniture hardware acceptance: GB/T 3325 general technical requirements for metal furniture hardware; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
