Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (main desk + right return) | 2200 x 1800 x 760 mm | |
|---|---|---|
| Main work surface width | 1800 mm | |
| Main work surface depth | 900 mm | |
| Right return surface width | 1200 mm | |
| Right return surface depth | 600 mm | |
| Desktop panel thickness | 50 mm | |
| Seated knee clearance height | 620 mm | |
| Knee clearance width (central opening) | 700 mm | |
| Knee clearance depth under desk | 600 mm | |
| Right return storage cabinet height | 650 mm | |
| Desk plinth base height | 120 mm | |
| Cable grommet diameter | 60 mm | |
| Leather desk inset mat size | 1200 x 600 mm | |
| Front modesty panel thickness | 30 mm | |
| Edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total desktop static load capacity | 363 kg | |
|---|---|---|
| Drawer slide static load per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 100000 cycles | |
| Desktop finish abrasion resistance | 2000 cycles | |
| Net product weight | 144 kg | |
| Recommended user weight capacity | 150 kg | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desk frame and structural panels | Hardwood solids with cherry wood veneer, polished clear lacquer topcoat | |
|---|---|---|
| Work surface inset | 3 mm thick top-grain leather writing mat, stitched edge trim | |
| Drawer hardware | Full-extension cold-rolled steel ball-bearing slides, brass-plated lock cylinders | |
| Desk base and plinth feet | Solid hardwood block feet with reinforced corner joinery | |
| Front modesty panel | Solid wood veneer raised panel with molded edge detailing | |
| Cable management components | ABS plastic grommets, powder-coated steel under-desk cable tray |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lockable storage on right return | Keyed central lock secures 2 file drawers and 1 supply drawer for document security | |
|---|---|---|
| Cable management system | Dual desktop grommets route power/data cables to under-desk tray, eliminating surface clutter | |
| Adjustable floor stability | 4 adjustable levelers at base corners compensate for uneven floor surfaces | |
| Pull-out writing surface | Concealed pull-out shelf under main desktop provides extra temporary work space |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Formal traditional styling suited for senior management and executive private workspaces | |
|---|---|---|
| Paired suite configuration | Designed to coordinate with matching wood filing cabinets, leather executive chairs and visitor seating |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2018 | Office work tables - safety, strength and durability requirements for office desks | |
|---|---|---|
| EN 13722:2004 | Furniture - strength, durability and stability requirements for storage units in office furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products - static, dynamic and durability performance requirements |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable if engineered wood components are used in drawer interiors | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances in wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and finish quality; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable if engineered wood components are used in drawer interiors; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances in wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
