Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 185 kg | |
|---|---|---|
| Distributed worktop load | 80 kg | |
| Pedestal and cabinet static load | 60 kg | |
| Desktop point load | 25 kg | |
| Seating capacity | 1 person | |
| Edge impact design target | 45 kg drop at 100 mm | |
| Hardware cycle target | 50000 operations | |
| Surface heat-resistance target | 80 degrees C for 20 minutes | |
| Recommended service life target | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop substrate | 30 mm wood-based panel substrate with high-gloss reddish-brown wood veneer or veneer-print laminate | |
|---|---|---|
| Molded edge and trim | Stained wood or veneered MDF edge molding with layered profile | |
| Cabinet panels | 18 mm wood-composite furniture board with matching veneered faces | |
| Decorative front inset | Black leather-look upholstered panel with diamond stitching and wood frame | |
| Desk pad | Black leather-look or synthetic leather writing surface with finished edge | |
| Hardware | Metal hinges, drawer slides, handles and lock cylinder with brass-tone or dark finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Workstation layout | L-shaped layout provides a 2400 mm primary writing surface and a 1200 mm left return for documents or devices | |
|---|---|---|
| Storage structure | Panel-base storage encloses the left return and both front support ends, with a central knee opening and lockable cabinet hardware target | |
| Cable and equipment provision | Procurement configuration should include one 60 mm cable grommet and an internal PC compartment clearance of 250 x 450 x 500 mm | |
| Privacy and modesty design | The 820 mm wide front decorative panel screens the seated leg area while retaining a 620 mm knee height |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Export carton dimensions | 2500 x 1150 x 220 mm, 1350 x 750 x 180 mm, and 1850 x 700 x 720 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office | Suits a private manager office where the broad main top supports a computer and documents while the left return provides meeting or filing space | |
|---|---|---|
| Senior administrative workspace | Appropriate for directors, legal offices or sales managers needing a formal reception-facing desk and concealed under-desk storage |
EU Market Access Requirements* EN Standards
| EN 527-1 office desk safety | Applicable standards and test results require confirmation | |
|---|---|---|
| EN 527-2 office desk mechanical tests | Applicable reference for strength, durability and stability test methods | |
| EN 15372 office furniture durability | Applicable reference for strength, durability and safety requirements for non-domestic storage and desk components | |
| EN 717-1 formaldehyde release | Applicable reference for wood-based panel formaldehyde emission by chamber method | |
| EN 13722 bending strength | Applicable reference when curved or molded wood-composite support panels are used |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324 dimensional and structural suitability | Applicable procurement reference for wooden furniture dimensions, tolerances and workmanship inspection | |
|---|---|---|
| GB/T 3325 wooden furniture durability | Applicable reference for strength, stability and durability testing of wooden office furniture | |
| GB 18584 formaldehyde control | Applicable indoor wooden-furniture furniture emission reference for panel substrate acceptance | |
| GB/T 4893.4 surface abrasion | Applicable reference for coated furniture-surface abrasion acceptance | |
| GB/T 4893.2 wet heat resistance | Applicable reference for resistance to wet heat on finished wood furniture surfaces |
This product must meet the following technical requirements: 1. GB/T 3324 dimensional and structural suitability: Applicable procurement reference for wooden furniture dimensions, tolerances and workmanship inspection; 2. GB/T 3325 wooden furniture durability: Applicable reference for strength, stability and durability testing of wooden office furniture; 3. GB 18584 formaldehyde control: Applicable indoor wooden-furniture furniture emission reference for panel substrate acceptance; 4. GB/T 4893.4 surface abrasion: Applicable reference for coated furniture-surface abrasion acceptance; 5. GB/T 4893.2 wet heat resistance: Applicable reference for resistance to wet heat on finished wood furniture surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
