Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed desktop static load | 120 kg | |
|---|---|---|
| Pedestal drawer static load | 25 kg per drawer | |
| Side cabinet shelf load | 20 kg per level | |
| Recommended user size | One executive user | |
| Chair circulation width behind seat | 800 mm | |
| Net weight range | 185 kg | |
| Desktop point load | 40 kg at 200 x 200 mm | |
| Drawer slide durability | 50,000 opening cycles | |
| Warranty target | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate and veneer | 18 mm engineered-wood substrate with red-brown wood veneer and glossy lacquer; grade requires supplier BOM confirmation | |
|---|---|---|
| Edge and apron construction | Veneered molded edge, raised panels, and carved-look decorative overlays on a 90 mm front apron | |
| Side pedestal | 16 mm veneered engineered-wood panels with flush exterior door face and central cylinder lock | |
| Desk mat | Black leather-look or PU writing surface over a rigid backing, visible in the laptop work zone | |
| Base and plinth | Veneered panel plinth with carved end panels and continuous floor rail, inferred from visible construction | |
| Hardware | Metal drawer slides, hinges, and chrome- or brass-toned lock cylinder; exact grade needs BOM confirmation |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Left return contains a lockable pedestal with three drawer bays sized for stationery, files, and personal items | |
|---|---|---|
| Cable management | Two 60 mm desk grommets and a rear cable channel route laptop, monitor, power, and network cables below the work surface | |
| Privacy modesty panel | Full-width 520 mm front panel blocks knee-space view while preserving seated leg clearance | |
| Fixed panel-base support | Wide end supports and plinth transfer load directly to the floor; no height adjustment or folding function |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office | Suits a manager or director office where laptop work, meetings, and document storage occur at one substantial desk | |
|---|---|---|
| Private management suite | Pairs with the matching bookcase and leather reception seating shown for a traditional formal workplace |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
