Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed desktop static load | 80 kg | |
|---|---|---|
| Pedestal drawer rated load | 25 kg per drawer | |
| Pedestal cabinet shelf load | 30 kg | |
| Recommended user weight at workstation | 120 kg | |
| Net weight range for quotation | 165 kg | |
| Worktop surface durability target | 30000 abrasion cycles | |
| Recommended office floor live-load condition | 2.5 kPa per square metre | |
| Warranty duration | 5 years | |
| Available finish count | 1 visible red-brown finish | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate and veneer | Engineered-wood substrate with red-brown wood veneer or wood-grain melamine and polished lacquer topcoat | |
|---|---|---|
| Edge and decorative trim | Stained wood or wood-composite molded trim with layered edge banding | |
| Modesty and pedestal panels | 18 mm wood-composite panels with matching veneer finish | |
| Writing surface | Black leatherette or soft PVC pad bonded to a hard backing | |
| Drawer and door hardware | Metal drawer runners, hinges, handles, and lock barrel in brass-tone or brown finish | |
| Base and leveling components | Wood-look plinth with concealed glides or small leveling feet |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| L-shaped work configuration | Main desk supports computer-facing work while the left return provides document, meeting, or secondary-device space | |
|---|---|---|
| Storage and seating arrangement | Left box pedestal supplies enclosed storage while preserving a 700 mm central knee bay for one executive chair | |
| Cable management | Two 60 mm rear desktop grommets allow laptop and power leads to pass below the work surface | |
| Installation and leveling | Knock-down panel assembly uses cam bolts, connecting brackets, drawer runners, and adjustable floor glides for a 52 mm level adjustment |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Master carton dimensions | 2400 x 1150 x 720 mm for the largest desktop pack | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office | Suits a manager or director office where laptop work, signing, document review, and pedestal storage occur at one 2800 mm L-shaped workstation | |
|---|---|---|
| Formal reception or management meeting room | Pairs with leather visitor seating and matching wood bookcases for a high-level administrative or reception meeting setting |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Defines safety, strength, and dimensional requirements for office desks including knee clearance and stability | |
|---|---|---|
| EN 527-2:2002 | Provides mechanical safety, durability, and stability test methods for office work surfaces and supports | |
| EN 15372:2016 | Applies to strength, durability, and stability requirements for non-domestic storage furniture in the pedestal | |
| EN 717-1:2004 | Covers formaldehyde release from wood-based panels by chamber method for indoor air-quality verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable desk test standard for load, cycle, drop, and stability performance in commercial offices | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable to storage components if the pedestal contains drawers, doors, or locks | |
| ANSI/BIFMA e3-2019 | Optional sustainability and material-transparency framework for furniture procurement documentation |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standards and test results require confirmation | |
|---|---|---|
| GB/T 3325-2017 | Applies to metal furniture hardware performance where drawer runners and locks are supplied | |
| GB 18584-2001 | Applies to formaldehyde-release and soluble-metal limits for indoor wooden furniture | |
| GB/T 4893.4-2013 | Applies to surface adhesion testing of finished wood-furniture coatings | |
| GB/T 4893.8-2013 | Applies to abrasion resistance of furniture surface films |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standards and test results require confirmation; 2. GB/T 3325-2017: Applies to metal furniture hardware performance where drawer runners and locks are supplied; 3. GB 18584-2001: Applies to formaldehyde-release and soluble-metal limits for indoor wooden furniture; 4. GB/T 4893.4-2013: Applies to surface adhesion testing of finished wood-furniture coatings; 5. GB/T 4893.8-2013: Applies to abrasion resistance of furniture surface films; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
