L-shaped Traditional Chinese Red Wood Veneer Executive Desk with Hui-style Fret Carving (model EXD-L-CHN-3200) is listed under Traditional CEO Desk, with overall dimensions of 3200 × 2200 × 760 mm and main material of MDF. Load capacity: 150 kg. Certifications: Traditional,Chinese,formal,style,L-shaped,dual-pedestal,structure,cable,management,integrated,leather,panel,details. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W×D×H) | 3200 x 2200 x 760 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Main work section depth | 1180 mm | |
| Side return length | 1600 mm | |
| Side return depth | 600 mm | |
| Central knee well width | 800 mm | |
| Central knee well height | 650 mm | |
| Knee well depth under worktop | 600 mm | |
| Leather writing mat dimensions | 1600 x 600 mm | |
| Cable grommet diameter | 80 mm | |
| Drawer front panel thickness | 18 mm | |
| Plinth base height | 80 mm | |
| Solid wood edge trim thickness | 3 mm | |
| Fret carved decorative panel size | 600 x 400 mm | |
| Drawer internal depth (file drawers) | 480 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop distributed static load | 150 kg | |
|---|---|---|
| Single drawer dynamic load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Cable tray load capacity | 10 kg | |
| Desk net weight | 180 kg | |
| Recommended user weight capacity | 136 kg | |
| Factory warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Core substrate | E1 grade high-density fiberboard | |
|---|---|---|
| Surface finish | Natural red wood veneer with high-gloss PU paint | |
| Work mat and drawer panels | Black stitched top-grain bonded leather | |
| Decorative trim and carvings | Solid hardwood carved Hui-style fret panels | |
| Hardware components | Zinc alloy drawer pulls, cold-rolled steel ball-bearing slides | |
| Cable management parts | ABS plastic grommets, steel under-desk cable tray |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Dual pedestal storage with four utility drawers and two legal-size file drawers plus CPU compartment | |
|---|---|---|
| Cable management | Three embedded desktop grommets with under-desk cable tray routing | |
| Return orientation | Field-reversible side return for left or right installation | |
| Ventilation design | Perforated rear panels for PC tower compartment heat dissipation |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Designed for senior management and C-suite formal office spaces, matching traditional decor schemes | |
|---|---|---|
| Government institutional office | Formal traditional styling suitable for administrative and government office environments |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, reference for structural performance validation | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for desk surface abrasion and stain resistance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, durability and stability testing reference | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard applicable to integrated desk pedestal drawers |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to finished desk dimensional tolerance and surface quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required for E1-grade substrate acceptance | |
| GB/T 4897.3-2003 | Performance requirements for particleboard/MDF used in furniture structural components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to finished desk dimensional tolerance and surface quality; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, required for E1-grade substrate acceptance; 3. GB/T 4897.3-2003: Performance requirements for particleboard/MDF used in furniture structural components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
